The VX–505, Extended Temperature Range (−55 to 125°C) High Frequency VCXO

Vectron-VX–505-VCXO

The VX-505 Voltage Controlled Crystal Oscillator provides a phase noise floor as low as -166dBc/Hz across the extended temperature range of -55°C to 125°C with a wide frequency range of 20MHz to 800MHz.

Features:

• AT-Cut Crystal
• Surface Mount FR4 based package
• Refl ow Process Compatible
• Extended temperature range -55..+125°C
• Low Phase Noise
• Tight Stabilities
• Frequency Range 20 – 800MHz
• Standard Frequencies 20; 30,72; 32,768; 38,88; 44.8;
61.44; 76.8; 77.76; 81.92; 92.16;100; 112; 122.88; 125;
134.4; 153.6; 155.52; 160; 179.2; 184.32; 195; 208; 245.76;
320; 368.64; 400; 448; 491.52; 640; 672; 737.28; 800MHz

Applications:

• Communication
• Industrial
• Harsh Environmental
• Military

Download:
Datasheet

www.vectron.com

Vectron

Vectron Generation Low g sensitivity TCXO

The TX-550 dual crystal temperature controlled crystal oscillator (TCXO) now offers a true sinewave output with an expanded frequency range from 8MHz to 100MHz and improved phase noise performance (-160dBc/Hz floor). It is offered in a 11.4 x 9.6mm footprint allowing designers to use higher frequencies in a compact form factor without requiring additional space-consuming multiplication circuits

ph_tx-550
Features
• Frequency Range: 8 to 100MHz
• Output: Sinewave, HCMOS, Clipped Sinewave
• Supply: 2.8, 3.3 or 5.0Vdc
• Package: 11.4 x 9.6 x 3.8mm
• Low g-sensitivity: 0.2ppb/g
• High Shock Survival: Up to 20Kg
• Frequency Stability: +/-1ppm over -40/85oC

Applications
• Airborne
• Radar
• Ground Mobile Applications
• GPS Telemetry

www.vectron.com

Vectron

OX–171 Next Generation High Stability OCXO with Improved Overall Performance in a Lower Profile Package

The Vectron International OX–171 is a high–stability ovenized crystal oscillator in a 28 x 38 x 12.7 mm package, capable of aging rates of 0.06 ppb/day and temperature stabilities of 1ppb over an industrial temperature range. Driven by an SC–cut crystal, the oscillator provides excellent phase noise and Allan Deviation.

Features:

  • Frequency range: 5 to 20 MHz
  • Supply: 3.3, 5.0 or 12Vdc
  • Package: 28 x 38 x 12.7 mm
  • Temperature stability: 0.4ppb over 0 to 70°C
  • Aging: 0.06ppb/day
  • g–sensitivity: 0.5ppb/g
  • Warm up: 5ppb in 5 minutes
  • Retrace performance: 2ppb

Applications:

  • Holdover reference
  • Test equipment
  • Synthesizers
  • Military communication equipment
  • Digital Switching

www.vectron.com
