ATEK564 RF Amplifier by ATEK MIDAS

The ATEK564 from ATEK MIDAS is a GaAs MMIC Driver Amplifier that operates from 5 to 22 GHz. It is designed for radar, SATCOM, SDR, RF testing, and electronic warfare transceiver, and is fabricated using GaAs pHEMT technology. This driver amplifier provides up to 26 dB of gain with a noise figure of 6 dB and an output P1dB of +22 dBm.

The ATEK564 integrates 50-ohm matched RF ports, DC blocks, and a self-bias configuration that requires only two external decoupling capacitors, minimizing the external component count. This amplifier requires a DC supply of 3 to 6 V and draws 123 mA of current. At a +3 V supply, it provides increased gain at reduced power consumption, making it suitable for low-power applications. It is available as a bare die measuring 1.250 × 1.250 mm.

Product Details

• Part Number: ATEK564
• Manufacturer: ATEK MIDAS
• Description: GaAs pHEMT MMIC Driver Amplifier from 5 to 22 GHz

General Parameters

• Type: Driver Amplifier
• Configuration: Die
• Application: Electronic Countermeasure (ECM), Electronic Warfare, Receivers, Radio, Radar Systems, Test & Measurement, Counter-UAS, Jammer Radar System
• Industry Application: Radar, Test & Measurement, Military
• Frequency: 5 to 22 GHz
• Gain: 20.7 to 25.8 dB
• Noise Figure: 6 dB
• P1dB: 0.05 to 0.1413 W
• P1dB: 17 to 21.5 dBm
• IP3: 30 dBm
• IP3: 1 W
• Saturated Power: 22.5 dBm
• Saturated Power: 0.178 W
• Input Power: 10 dBm
• Power Dissipation: 2.4 W
• Impedance: 50 Ohms
• Pulsed/CW: CW
• Reverse Isolation: 52 to 67 dB
• Input Return Loss: 13 dB
• Output Return Loss: 15 dB
• Supply Voltage: 3 to 6.5 V
• Current Consumption: 110 to 123 mA
• Package Type: Die
• Operating Temperature: -40 to 85 Degree C
• Storage Temperature: -55 to 125 Degree C
