The MFBP-00227CH from Marki Microwave is a Passive GaAs Band Pass Filter (BPF) MMIC with a passband from 8.4 to 10.1 GHz. It is suitable for applications that require high stopband rejection and fast roll-off in a compact form factor. This BPF is manufactured using GaAs MMIC technology, enabling smaller filter designs that replace larger form-factor circuit boards. It has a passband insertion loss of 28 dB, provides an out-of-band rejection of 30 dBc, and has a group delay of 774 ps. The manufacturing process of this filter also ensures tight fabrication tolerances, resulting in lower unit-to-unit variation than traditional filter technologies. This RoHS-compliant filter is available as a wire-bondable die measuring 3.10 x 3.10 mm. It has an EAR99 export classification.
Product Details
Part Number: MFBP-00227CH
Manufacturer: Marki Microwave
Description: Passive GaAs MMIC Band Pass Filter operating from 8.4 to 10.1 GHz, featuring low insertion loss, high stopband rejection and a compact wire-bondable die package.
General Parameters
|
Parameter |
Specification |
|
Type |
MMIC Filter |
|
Frequency |
8.4 to 10.1 GHz |
|
Center Frequency |
9.19 GHz |
|
Insertion Loss |
2.4 dB |
|
Rejection |
30 dB |
|
Return Loss |
28 dB |
|
Impedance |
50 Ohms |
|
Package Type |
Die |
|
Dimensions |
3.10 x 3.10 mm |
|
Operating Temperature |
-55 to 100 °C |
|
Storage Temperature |
-65 to 125 °C |
|
RoHS Compliant |
Yes |
|
Group Delay |
774 ps |
Get in touch for orders or any queries: sales@rfdesign.co.za / +27 21 555 8400
Courtesy of Marki Microwave
