AMM-11078CH RF Amplifier by Marki Microwave

The AMM-11078CH from Marki Microwave is a GaAs Distributed Amplifier that operates from 0.01 to 40 GHz. It delivers a saturated output power of 24 dBm, with a small-signal gain of 17.5 dB and a noise figure of 3.8 dB. This distributed amplifier is internally matched to 50 Ω at both the RF input and output ports, making it well-suited for wideband driver stages in RF/mmWave front ends. It provides a reverse isolation of 55 dB and has an input return pf 18 dB and an output return loss of 19 dB.

The AMM-11078CH requires a 7 V DC supply and draws less than 220 mA of current. It is available as a bare die measuring 2.4 x 1.68 mm and is ideal for SATCOM, 5G transceivers and test & measurement equipment.

Product Details

• Part Number: AMM-11078CH
• Manufacturer: Marki Microwave
• Description: Wideband GaAs Distributed Amplifier from 0.01 to 40 GHz

General Parameters

• Type: Driver Amplifier
• Configuration: Die
• Standards Supported: 5G
• Industry Application: Test & Measurement, SATCOM, Cellular, Radar
• Frequency: 10 MHz to 40 GHz
• Gain: 17.5 dB
• Small Signal Gain: 17.5 dB
• Noise Figure: 3.8 dB
• P1dB: 19.5 to 22 dBm
• IP3: 24 to 32.5 dBm
• Saturated Power: 21.7 to 25 dBm
• Input Power: 10 to 15 dBm
• Impedance: 50 Ohms
• Pulsed/CW: CW
• Reverse Isolation: 55 dB
• Sub-Category: Distributed Amplifier
• Input Return Loss: 18 dB
• Output Return Loss: 19 dB
• Supply Voltage: 4 to 8 V
• Current Consumption: 150 to 230 mA
• Technology: GaAs
• Package Type: Surface Mount
• Dimensions: 1.38mm x 2.40mm
• Operating Temperature: -40 to 85 Degree C
• Storage Temperature: -65 to 150 Degree C
• RoHS: Yes
