The ADM-8095PSM is a high-linearity low noise amplifier capable of providing +21 dBm output power up to 10 GHz. The ADM-8095PSM can serve either as a linear signal amplifier, or as a saturated driver amplifier for H- or S-diode mixers. The amplifier has excellent return losses and gain flatness.
The ADM-8095PSM from Marki Microwave is a High Dynamic Range Gain Block that operates from 0.09 to 10 GHz. It can serve either as a linear signal amplifier or as a saturated driver amplifier for H- or S-diode mixers and requires no negative bias. This gain block provides a saturated output power of 21 dBm, a small-signal gain of 18 dB, and a noise figure of 1.5 dB. It has an input return loss of 17 dB and an output return loss of 21 dB.
The ADM-8095PSM requires a DC supply of 3 to 6 V and draws 39 mA of current. It is available in a DFN package measuring 1.3 × 2 mm. This RoHS- and REACH-compliant gain block is ideal for use in SATCOM, radar systems, mobile test and measurement equipment, 5G transceivers, and driver amplifier applications for H- and S-diode mixers.
Features
Applications
