New MMIC T3 Mixer Provides High Linearity With Expanded IF Capability

New MMIC T3 Mixer Provides High Linearity With Expanded IF Capability

Courtesy of Marki Microwave : New MMIC T3 Mixer Provides High Linearity With Expanded IF Capability

High Linearity Triple-Balanced MMIC Mixer for S, C, X-Band

The MT3L-0113HSM is a lower IF variant of our popular MT3H-0113HSM triple-balanced MMIC mixer. It offers similar linearity performance to our T3-07, T3-12, and MT3-0113CQG mixers with smaller size, better availability, and a lower price. Greater than +30dBm IIP3 can be achieved when paired with our ADM series of square-wave generating LO driver amplifiers. Sine-wave operation is also supported. RF and LO cover 1.5 to 13 GHz, and the IF is 0.25 to 5 GHz. With 40 dB of port-to-port isolation and over 60 dBc spurious suppression, this latest entry to the T3 product family is ideal for high performance radar, radio and test applications. MT3L-0113HSM is available in a surface-mount QFN or connectorized evaluation module.

Product Page Datasheet RF/LO

[GHz]

IF

[GHz]

LO Drive

[dBm]

Conversion Loss

[dB]

Isolation

L-R

[dB]

IIP3

[dBm]

 MT3L-0113HSM pdf 1.5 to 13 0.25 to 5 +15 to +25 8.5 39 +31



The T3 Mixer Product Family

Our  T3 mixers is the most advanced mixer circuit available in the world. In addition to broadband overlapping LO, RF, and IF bands, it has the potential for extremely high linearity. T3 mixers are built in both hybrid and MMIC form. The hybrid construction allows for ultra-broadband coverage on all three ports (RF,LO, and IF), whereas the MMIC MT3 series offers the scalability and repeatability of a MMIC with the linear performance of the T3.  Click here for our full lineup of bare die, surface mount, and connectorized T3 mixers up to 40 GHz.



LO Drivers for T3 Mixers

The T3 mixer is a true-commutating mixer. This means it will provide increasing two-tone intermodulation suppression, input 1-dB compression, and spurious suppression (for most spurs) as the rise time of the LO signal is increased by either increasing sine wave LO drive or, for optimal results, using a square wave LO. The ADM series amplifiers were designed to provide strong odd (3rd and 5th) harmonics and are an ideal choice as a square wave LO generator for the T3 mixers.



T3 Mixer Primer

The Two-Tone-Terminator (T3) mixer is the most sophisticated mixer circuit on the market today and offers unparalleled performance when compared to all other mixer technologies. To learn the theory behind its operation and how this directly translates to improved P1dB, IP3 and spurious performance, download our T3 Primer.

MFB-1100 Band Pass Filter by Marki Microwave

MFB-1100 Band Pass Filter by Marki Microwave

Courtesy of everything RF : MFB-1100 Band Pass Filter by Marki Microwave

The MFB-1100 from Marki Microwave is a Band Pass Filter with Frequency 9 to 13 GHz, Bandwidth 3 GHz, Center Frequency 11 GHz, Insertion Loss 2 to 3 dB, Rejection 20 to 50 dB. Tags: Die. More details for MFB-1100 can be seen below

Product Details

    • Part Number : MFB-1100
    • Manufacturer : Marki Microwave
    • Description : 9 to 13 GHz, Band Pass Filter Die

General Parameters

    • Application : X Band
    • Frequency : 9 to 13 GHz
    • Bandwidth : 3 GHz
    • Center Frequency : 11 GHz
    • Insertion Loss : 2 to 3 dB
    • Rejection : 20 to 50 dB
    • Return Loss : 17 dB
    • Impedance : 50 Ohms
    • Package Type : Die
    • Operating_Temperature : -55 to 100 Degree C
    • Storage_Temperature : -65 to 125 Degree C
    • Grade : Commercial, Space
    • RoHS : Yes
MMIQ-1865H RF Mixer by Marki Microwave

MMIQ-1865H RF Mixer by Marki Microwave

Courtesy of Marki Microwave : MMIQ-1865H RF Mixer

The MMIQ-1865H from Marki Microwave is a passive GaAs MMIC IQ mixer with a RF/LO frequency range from 18 to 65 GHz and IF range from DC to 23 GHz. It provides up to 35 dB of image rejection due to the excellent phase and amplitude balance of its on-chip LO quadrature hybrid. The mixer is available as a wire bondable die or a connectorized module and is ideal for band shifting, vector amplitude modulation, single side band and image rejection mixing applications.

Product Details

    • Part Number : MMIQ-1865H
    • Manufacturer : Marki Microwave
    • Description : Passive GaAs MMIC IQ Mixer from 18 to 65 GHz

General Parameters

    • Type : I/Q Mixer
    • RF Frequency : 18 to 65 GHz
    • LO Frequency : 18 t 65 GHz
    • IF Frequency : DC to 23 GHz
    • Image Rejection : 35 dB
    • Conversion Loss : 9 dB
    • Noise Figure : 11 to 12 dB
    • LO Drive – Power : 15 to 21 dBm
    • IP3 : 21 dBm
    • LO/RF Isolation : 48 dB
    • Impedance : 50 Ohms
    • Package Type : Module with Connectors, Die
    • Operating Temperature : -55 to 100 Degrees C
    • Storage Temperature : -65 to 125 Degrees C
    • RoHS : Yes
Marki-Microwave-Two-New-MMIC-IQ-Mixers

Marki Microwave Two New MMIC IQ Mixers: 4-16 GHz & 18-65 GHz

Courtesy of Marki Microwave : Two New MMIC IQ Mixers: 4-16 GHz & 18-65 GHz

K/Ka/V-Band IQ Mixer Features

Massive 23 GHz IF Bandwidth

This is our best mmwave IQ mixer yet! The MMIQ-1865L/H features an astounding 50dB of L-to-R isolation across a wide 18 to 65 GHz frequency range. Combined with 23 GHz of IF bandwidth, this MMIC mixer is the ideal solution for wideband IQ and vector modulation, band shifting, and much more at K, Ka, and V bands. Excellent amplitude and phase matching result in 35dB of image rejection. We offer two diode options: MMIQ-1865H for high linearity and MMIQ-1865L for low power applications. Both are available in bare die or connectorized module. For best performance, the AMM-6702 is recommended to supply the high power levels required for the MMIQ-1865L/H.



Product Page Datasheet RF/LO

[GHz]

IF

[GHz]

LO Drive

[dBm]

Conversion Loss

[dB]

Isolation

L-R

[dB]

IIP3

[dBm]

MMIQ-1865L pdf 18 to 65 DC to 23 +8 to +17 9 50 15
MMIQ-1865H pdf 18 to 65 DC to 23 +15 to +21 9 48 23



MMIQ-1865L:

MMIQ-1865L:

High Linearity, High Suppression

4 to 16 GHz IQ Mixer

Need the best carrier and sideband suppression for your C/X/Ku-band upconverter? We designed the MMIQ-0416HSM IQ mixer to acheive the best phase and amplitude balance possible over a wide RF/LO bandwidth of 4 to 16 GHz and an IF of DC to 6GHz IF. This MMIC IQ mixer provides an awesome 50dBc of L-R isolation and a high P1dB of +10dBm on each I and Q port.  Ideal for I/Q modulation, vector modulation and pairing with quad hybrids for image-reject and single-sideband mixing. Available in 4x4mm QFN or connectorized evaluation module. For low drive applications, we offer the MMIQ-0416LSM.



Product Page Datasheet RF/LO

[GHz]

IF

[GHz]

LO Drive

[dBm]

Conversion Loss

[dB]

Img Rej

[dB]

Isolations L-R

[dB]

Isolations

L-I

[dB]

MMIQ-0416HSM pdf 4 to 16 DC to 6 +13 to +22 8.5 31 51 39





MEQ10-50AU

MEQ10-50AU Gain Equalizer by Marki Microwave

Courtesy of everything RF : MEQ10-50AU Gain Equalizer by Marki Microwave

The MEQ10-50AU from Marki Microwave is a Gain Equalizer with Frequency DC to 50 GHz, Gain Equalization 10 dB, Insertion Loss 1.8 to 3 dB, Impedance 50 Ohms, Operating Temperature -55 to 100 Degrees C. Tags: Module with Connectors, Positive Gain Slope. More details for MEQ10-50AU can be seen below.

Product Details

      • Part Number : MEQ10-50AU
      • Manufacturer : Marki Microwave
      • Description : 50GHz, Passive GaAs MMIC Equalizer

General Parameters

      • Type : Positive Gain Slope
      • Frequency : DC to 50 GHz
      • Gain Equalization : 10 dB
      • Insertion Loss : 1.8 to 3 dB
      • return_loss : 10 to 15 dB
      • Package Type : Module with Connectors
      • Connector : 2.4 mm, 2.4 mm – Female, 2.4 mm – Male
      • Impedance : 50 Ohms
      • Operating Temperature : -55 to 100 Degrees C
      • Storage Temperature : -65 to 125 Degrees C
MT3L-0113H RF Mixer by Marki Microwave

MT3L-0113H RF Mixer by Marki Microwave

Courtesy of everything RF : MT3L-0113H RF Mixer by Marki Microwave

The MT3L-0113H from Marki Microwave is a GaAs triple balanced MMIC mixer with an RF/LO frequency from 1.5 to 13 GHz and IF frequency from 0.25 to 5 GHz. The mixer has a conversion loss of 8.5 dB, isolation of 43 dB and a high dynamic range. The high isolation and spur suppression make this mixer ideal for high performance radar, radio and test applications.

The MT3L-0113H is available as both a wire bondable die and a connectorized module. Customers can also contact Marki Microwave to check on availibility of this mixer in a QFN package.

Product Details

    • Part Number : MT3L-0113H
    • Manufacturer : Marki Microwave
    • Description : 1.5 to 13 GHz, GaAs Triple Balanced Mixer

General Parameters

    • Type : Triple Balanced Mixer
    • RF Frequency : 1.5 to 13 GHz
    • LO Frequency : 1.5 to 13 GHz
    • IF Frequency : 0.25 to 5 GHz
    • Conversion Loss : 8.5 to 11.5 dB
    • Noise Figure : 8.5 dB
    • LO Drive – Power : 15 to 25 dBm
    • P1dB : 20 dBm
    • IP3 : 31 dBm
    • LO/RF Isolation : 43 dB
    • LO/IF Isolation : 41 dB
    • Impedance : 50 Ohms
    • Package Type : Module with Connectors, Die
    • Connector : SMA, SMA – Female
    • Operating Temperature : -55 to 100 Degrees C
    • Storage Temperature : -65 to 125 Degrees C
    • RoHS : Yes
New High Linearity, High Isolation Mixers in Bare Die, SMT, and Module

New High Linearity, High Isolation Mixers in Bare Die, SMT, and Module

Courtesy of Marki Microwave : New High Linearity, High Isolation Mixers in Bare Die, SMT, and Module

High Linearity Triple-Balanced MMIC Mixer for S, C, X-Band

The MT3L-0113H is a lower IF variant of our popular  MT3H-0113H triple-balanced MMIC mixer. Greater than +30dBm IIP3 can be achieved when paired with our ADM series of square-wave generating LO driver amplifiers. RF and LO cover 1.5 to 13 GHz, and the IF is 0.25 to 5 GHz.  WIth port isolations greater than 40 dB and spur suppression over 60 dBc, this latest entry to the T3 product family is ideal for high performance radar, radio and test applications. MT3L-0113H is available now as bare die or connectorized module. Contact us for surface-mount QFN availability.

Product Page Datasheet RF/LO

[GHz]

IF

[GHz]

LO Drive

[dBm]

Conversion Loss

[dB]

Isolation

L-R

[dB]

IIP3

[dBm]

 MT3L-0113H  pdf 1.5 to 13 0.25 to 5 +15 to +25 8.5 43 +31



High Isolation, High Linearity 8 to 32 GHz SMT Mixers

The MM1-0832LSM/HSM double-balanced GaAs MMIC mixers from Marki Microwave are a great solution for X through Ka bands with full coverage for SATCOM and 28 GHz 5G applications. RF is a wide 8 to 32 GHz, LO is 8 to 30 GHz, and IF spans DC to 12 GHz. The high linearity MM1-0832HSM provides +22dBm IIP3 with an LO of +18dBm, while the MM1-0832LSM offers a low drive option requiring just +8dBm LO. Both versions of the MM1-0832 feature exceptional spurious suppression and port to port isolations to support demanding frequency plans. MM1-0832LSM and MM1-0832HSM are available in surface-mount QFN and connectorized evaluation modules.

Product Page Datasheet RF/LO

[GHz]

IF

[GHz]

LO Drive

[dBm]

Conversion Loss

[dB]

Isolation

L-R

[dB]

IIP3

[dBm]

MM1-0832LSM pdf 8 to 32 DC to 12 +8 to +15 8.5 36 +11
MM1-0832HSM pdf 8 to 32 DC to 12 +16 to +23 8 36 +25.5

MM1-0823LSM



MM1-0823HSM

MM1-1850S RF Mixer by Marki Microwave

MM1-1850S RF Mixer by Marki Microwave

Courtesy of everything RF : MM1-1850S RF Mixer by Marki Microwave

The MM1-1850S from Marki Microwave is a RF Mixer with RF Frequency 18 to 50 GHz, LO Frequency 18 to 50 GHz, IF Frequency DC to 20 GHz, Conversion Loss 8.5 dB, P1dB 14 dBm. Tags: Die, Module with Connectors, Double Balanced Mixer. More details for MM1-1850S can be seen below.

Product Details

    • Part Number : MM1-1850S
    • Manufacturer : Marki Microwave
    • Description : 18 to 50 GHz, GaAs Double Balanced Mixer

General Parameters

    • Type : Double Balanced Mixer
    • RF Frequency : 18 to 50 GHz
    • LO Frequency : 18 to 50 GHz
    • IF Frequency : DC to 20 GHz
    • Conversion Loss : 8.5 dB
    • P1dB : 14 dBm
    • IP3 : 25 dBm
    • Package Type : Die, Module with Connectors
    • Dimension : 0.058” x 0.046” x 0.004”
    • Connector : SMA
New active Doubler Modules Produce High Power from 4 to 30 GHz

New active Doubler Modules Produce High Power from 4 to 30 GHz

Courtesy of Marki Microwave : New active Doubler Modules Produce High Power from 4 to 30 GHz

Marki Microwave’s two new unique frequency doublers provide wide output bandwidths, high output power and high harmonic suppressions. The ADA-0416 output spans 4 to 16 GHz and the ADA-1030 covers 10 to 30 GHz. Both are active devices accepting inputs of 0 to +6dBm and providing doubled outputs at +13 to +16dBm, ideal for driving our L and H-diode mixers. As an added bonus these units also serve as multi-component evaluation modules for the surface-mount amplifiers, bias tees, and multiplier contained within.

Product Page Datasheet Input

[GHz]

Output [GHz] Input Level [dBm] Output Level

[dBm]

Typical Suppression [avg] Bias

[V/mA]

ADA-0416  pdf 2 to 8 4 to 16 +0 to +6 +16 28 +7V/-0.15@

300mA

ADA-1030 pdf 5 to 15 10 to 30 +0 to +6 +16 30  +7V/-0.15@

300mA

QH-0R518-3-dB Quadrature (90-degree) Hybrid Coupler

Marki Microwave QH-0R518 3 dB Quadrature (90 degree) Hybrid Coupler

Courtesy of Marki MicrowaveQH-0R518 3 dB Quadrature (90 degree) Hybrid Coupler

Quad Hybrid Features Industry-Best 36:1 BW Ratio

The new QH-0R518 quadrature hybrid coupler achieves an astounding 36:1 bandwidth ratio, from 0.5 GHz to 18 GHz. Featuring excellent amplitude and phase balance, high 20dB isolation, and 20W power handling this 90 degree quad coupler enables a variety of applications such as single sideband conversion, image rejection, IQ modulation, balanced amplifiers and more. Check out our full selection of quadrature hybrids that extend to 67 GHz.

Product Page Datasheet Frequency Band

[GHz]

Coupling

[dB]

Amplitude Balance

[dB]

Phase Balance [degrees] Isolation

[dB]

QH-0R518  pdf 0.5 to 18 3 ± 0.5 ± 3 20
