HFHKI-3100+ RF High Pass Filter by Mini-Circuits The HFHKI-3100+ from Mini-Circuits is a RF High Pass Filter with Frequency 3500 to 12500 MHz, Bandwidth 9000 MHz, Insertion Loss 1 to 2.6 dB, Power 6 W, Rejection 23 to 70 dB. Tags: Surface Mount, Ceramic Filter. More details for HFHKI-3100+ can be seen below. Product Details Part Number:...

COHKI-3002+ RF Crossover by Mini-Circuits The COHKI-3002+ from Mini-Circuits is an LTCC RF Crossover that operates from DC to 30 GHz. It is designed to route RF transmission lines without requiring additional PCB layers for compact, high-density RF front-end designs. This 50-ohm RF crossover has an insertion loss of 1.1 dB and an isolation of 45 dB....

Mini-Circuits New Model Alert- Cut PCB Layers with RF Crossovers DC to 30 GHz, µCeramIQ RF Crossover, Simplify Complex RF Layouts without Adding Extra Layers. Mini-Circuits COHKI-3002+ µCeramIQ RF crossover is an innovative surface-mount component that allows two transmission lines to physically cross each other on a circuit board without introducing adverse effects to system...

Mini-Circuits ZBT-44-1A-FT+ 43.5GHz 1.3A Bias Tee Connector Type: 2.92mm KEY FEATURES Wideband coverage, 10 MHz to 43.5 GHz Low insertion loss, 1.2 dB typ. Excellent return loss, 15 dB typ. Excellent isolation, 40 dB typ. High DC input current, 1.3 A max APPLICATIONS Broadband communication Wideband test & measurement 4G LTE & 5G FR1 infrastructure...

HFHKI-1600+ RF High Pass Filter by Mini-Circuits The HFHKI-1600+ from Mini-Circuits is a RF High Pass Filter with Frequency 1900 to 9500 MHz, Bandwidth 7600 MHz, Insertion Loss 0.8 to 2.5 dB, Power 6 W, Rejection 20 to 72 dB. Tags: Surface Mount, Ceramic Filter. More details for HFHKI-1600+ can be seen below. Product Details Part Number:...

Mini-Circuits New Model Alert- 1x1mm MMIC Fixed Attenuators DC to 45 GHz, The Industry's Smallest Fixed Attenuators, 0-10 dB Attenuation in 1x1mm Footprint The new XAT-Series redefines RF miniaturization with the industry's smallest MMIC fixed attenuators. Housed in an ultra-compact 2-lead, 1×1 mm QFN package, these attenuators enable significant PCB space savings for next-generation high-density...

Impact of Additive Phase Noise on Frequency Multiplier Chains for SATCOM Mini-Circuits Vice President of Engineering, Joe Merenda discusses the impact of additive phase noise on frequency multiplier chains using SATCOM frequency converter example. The talk covers BUC reference design, PLL schematic diagram, brass board implementation, spectral analysis, filter technologies, additive phase noise theory, cascade...

GNA-63-5W+ RF Amplifier by Mini-Circuits The GNA-63-5W+ from Mini-Circuits is a GaN MMIC Power Amplifier (PA) that operates from 10 MHz to 6 GHz. It is designed for high-power RF applications requiring high efficiency, excellent linearity, and a compact footprint. This PA delivers a saturated output power of +38.5 dBm (~6 W) with a large-signal gain of...

SSG-R7N6GD-RC Signal Generator by Mini-Circuits The SSG-R7N6GD-RC from Mini-Circuits is a Dual-Channel Signal Generator that operates from 700 to 6000 MHz. It is designed to provide a cost-effective broadband signal source for bench and production test applications requiring high output power and flexible signal generation. This signal generator supports two independently tunable channels and can generate CW,...

AN-60-149: Setting Up GaAs/GaN MMIC RF Power Amplifier Evaluation Boards for Bench Testing Bias Sequencing of Depletion Mode Devices Such as GaAs and GaN MMIC RF Power Amplifiers This application note (download pdf version here) provides a structured procedure to prepare and test depletion mode devices such as GaAs and GaN MMIC RF power amplifier...
