ATNXX-0067CH Fixed Attenuator by Marki Microwave
The ATNXX-0067CH from Marki Microwave are Fixed Attenuators that operate from DC to 67 GHz. They are available in attenuation values from 0 to 10 dB with 1 dB steps and can handle an input power of up to 2 W. These GaAs attenuators are available as wire bondable dies that measure 0.60 x 0.60 mm and are ideal for attenuating signals in a wide range of applications such as test equipment protection and signal overload prevention in RF systems.
Product Details
- Part Number: ATNXX-0067CH
- Manufacturer: Marki Microwave
- Description: 0 to 10 dB Fixed Attenuator MMICs from DC to 67 GHz
General Parameters
- Frequency: DC to 67 GHz
- Attenuation: 0 to 10 dB
- Power: 2 W
- Package Type: Die
- Grade: Commercial
- Impedance: 50 Ohms
- RoHS: Yes
- Attenuation Accuracy: ±0.1 to ±0.7 dB
- Operating Temperature: -55 to +100 Degree C
- Storage Temperature: -65 to +125 Degree C
- Note: Return Loss: 30 to 44 dB
