QPA9862 RF Amplifier by Qorvo

The QPA9862 from Qorvo is a Pre-Driver Amplifier that operates from 3.3 to 4.2 GHz. It delivers a P3dB of +29.5 dBm (0.8 W) with a gain of 36.5 dB. This driver amplifier has an instantaneous bandwidth of more than 400 MHz and an Adjacent Channel Power Ratio (ACPR) of -48 dBc. It is internally matched to 50Ω over the entire operating frequency band and incorporates a fast enable/disable function for TDD operation. This amplifier requires a DC supply of +5 V and consumes 110 mA of current. It is available in an SMT package that measures 3 x 3 mm and is ideal for 5G m-MIMO, mobile infrastructure, general-purpose wireless, and TDD system applications.

Product Details

• Part Number: QPA9862
• Manufacturer: Qorvo
• Description: 0.8 W Pre-Driver Amplifier from 3.3 to 4.2 GHz


General Parameters

• Type: Driver Amplifier
• Configuration: IC/MMIC/SMT
• Standards Supported: 5G, FDD, TDD
• Industry Application: Cellular, Wireless Infrastructure
• Frequency: 3.3 to 4.2 GHz
• Gain: 36.5 dB
• Noise Figure: 3.8 dB
• Output Power: 29.5 (P3dB)
• Linear Power: 37 dBm
• Impedance: 50 Ohms
• Supply Voltage: 5 V
• Quiscent Current: 110 mA
• Package Type: Surface Mount
• Package: 16-Pin SMT Laminate
• Dimensions: 3.0 x 3.0 mm
• RoHS: Yes
