Qorvo QPD1025L

Qorvo QPD1025L

Courtesy of Qorvo QPD1025L

Qorvo’s QPD1025L was named a Gold Award winner in ’s 2018 Intelligent Aerospace Technology Innovation Awards! Learn more about the award-winning product here:

1800 Watt, 65 Volt, .96 – 1.215 GHz, GaN RF Input-Matched Transistor

Key Features

  • Frequency Range: .96- 1.215 GHz
  • Output Power (P3dB1): 1862 Watt
  • Linear Gain1: 22.5 dB
  • Typical PAE3dB1 77.2 %
  • Operating voltage: 65 V
  • CW and Pulse capable

Note1: @ 1.0GHz Load Pull

The Qorvo QPD1025L is a 1800 W (P3dB) discrete GaN on SiC HEMT which operates from .96to 1.215 GHz. Input prematch within the package results in ease of external board match and saves board space. The device is in an industry standard air cavity package and is ideally suited for IFF, avionics and test instrumentation. The device can support both CW and pulsed operations.

Lead-free and ROHS compliant.

Parameters:

Frequency Min(MHz) 960
Frequency Max(MHz) 1,215
Gain(dB) 22.5
Psat(dBm) 62.7
PAE(%) 77.2
VD(V) 65
Idq(mA) 1,500
Package Type NI-1230 (Eared)

Product Data Sheet Rev E – 11/2018

QPA2213 RF Amplifier

QPA2213 RF Amplifier by Qorvo

Courtesy of everything RF : QPA2213 RF Amplifier by Qorvo

The QPA2213 from Qorvo is a wideband GaN driver amplifier that operates from 2 to 20 GHz. This amplifier delivers 34 dBm of saturated output power and 25 dB of gain while achieving 25% power added efficiency. The module is available in a 4.5 x 4.5 x 1.74 mm laminate package and is ideal for both commercial and military-wide band or narrowband systems. It is fabricated on Qorvo’s production 0.15 um GaN on SiC process (QGaN15).

Product Specifications

Product Details

    • Part Number : QPA2213
    • Manufacturer : Qorvo
    • Description : 2 W GaN Amplifier from 2 to 20 GHz

General Parameters

    • Type : Driver Amplifier
    • Configuration : IC/MMIC/SMT
    • Industry Application : Radar, Commercial, Military
    • Frequency : 2 to 20 GHz
    • Power Gain : 16 dB
    • Small Signal Gain : 25 dB
    • Noise Figure : 4 dB
    • Saturated Power : 2 W
    • PAE : 23 %
    • Impedance : 50 Ohms
    • Sub-Category : GaN Amplifier
    • Input Return Loss : 12 to 29 dB
    • Phase Noise : 7 to 26 dB
    • Supply Voltage : 18 V
    • Current Consumption : 330 mA
    • Package Type : Surface Mount
    • Dimensions : 4.50 x 4.50 x 1.74 mm
    • Operating Temperature : -40 to 85 Degrees C
    • Storage Temperature : -55 to 125 Degrees C
    • RoHS : Yes
V2X in the Connected Car of the Future via Qorvo

V2X in the Connected Car of the Future

Courtesy of Qorvo : V2X in the Connected Car of the Future

The digital car is no longer a concept of the future. Automotive connectivity — or “connected car” applications — have now reached critical demand. Let’s look at the systems and networks that connect the car to the environment (V2X), the cloud (telematics), and infotainment for passengers and drivers.

This blog is an excerpt from Chapter 2 of our e-book, Connected Car For Dummies®.

V2X: Connecting to the Environment

The connected car, as depicted in the figure below, fits nicely into the developing ecosystem around the IoT. Although we typically think of vehicle-to-vehicle (V2V) connectivity — with lane obstruction or automatic braking alerts, soon the connected car will be a component of a smart city, driven by a multifaceted connected infrastructure and mobile devices.

Heterogeneous Connectivity

Imagine traffic lights automatically changing based on traffic patterns or responding to commute demands, or your car having the capability to search several city blocks for a parking spot — all enabled by the IoT.

V2X senses the environment to enable next-generation autonomy and real-time monitoring in the connected car. There are currently two key standards for V2X:

  • Institute of Electrical and Electronics Engineers (IEEE) 802.11p: 802.11p defines wireless access in vehicular environments (WAVE) including dedicated short-range communications (DSRC) devices in vehicles and roadside units (RSUs). It’s an amendment to the popular 802.11 wireless (Wi‑Fi) networking standards. DSRC operates in the 5.9 gigahertz (GHz) band with bandwidth of 75 megahertz (MHz) and an approximate range of 1,000 meters.
  • Cellular vehicular-to-everything (C‑V2X) cellular long-term evolution (LTE): C‑V2X is designed to support active safety and help enhance situational awareness by detecting and exchanging information using low-latency direct transmission in the 5.9 GHz Intelligent Transportation System (ITS) band for V2V, V2I, and vehicle-to-pedestrian (V2P) situations, with no need for cellular subscription or any network assistance. C‑V2X is defined by the Third Generation Partnership Project (3GPP) Release 14 specifications, including PC5-based direct communications, with a clear evolution path towards 5G New Radio (5GNR).

Today, IEEE 802.11p–based products are available on the market. Many of today’s vehicles are already equipped with IEEE 802.11p technology. In contrast, C‑V2X is just beginning its entrance into the automotive arena. With today’s cellular eco-system strength, C‑V2X will most likely mature quickly (see the following figure). There may be pros and cons to both technologies, but ultimately it will be a combination of consumer preference and technology that determines how well both technologies succeed in the 5G arena.

Glossary of Terms

See the end of our Connected Car For Dummiese‑book for definitions of key terms and acronyms used in this blog post.

C-V2X Communications

The next table compares DSRC and C‑V2X.

DSRC versus C-V2X

Vehicle safety is a common application for V2X, including:

  • V2V: For example, collision avoidance
  • V2I: For example, dynamic traffic signaling
  • V2P: For example, transmitting safety alerts to pedestrians and bicyclists
  • V2N: Vehicle-to-network — for example, real-time traffic and weather, custom navigation, and other cloud services

V2X will also enable more efficient fleet management and platooning with V2V communications.

Finally, V2X is being used to enhance the capabilities in advanced driver assistance systems (ADAS). ADAS typically employ cameras and radar sensors to provide visibility around a vehicle to a range of about 200 meters. V2X applications can share and coordinate information to extend the effective range of ADAS up to several kilometers.

Tip: LiDAR technologies such as onboard safety systems and sensors — for example, lasers, scanners, photodetector receivers, and GPS — also work alongside V2X and will be key enablers of autonomous vehicles.

Telematics: Vehicles Communicating with the Cloud

Telematics provides high-bandwidth connectivity for IoT integration and cloud services. Telematics has been used in commercial vehicles for quite some time to help businesses monitor and optimize various operational factors, such as:

  • Fuel consumption
  • Vehicle maintenance
  • Fleet utilization
  • Vehicle location
  • Optimum routing
  • Driver behavior

Telematics in the connected car of the future will encompass all cellular standards to deliver 1 gigabit per second (Gbps) capabilities, quickly following leading smartphone capabilities.

Technical Stuff: Gigabit LTE is poised to be included in everything from smartphones and laptops to portable hot spots and vehicles. Gigabit LTE refers to LTE Category 16 (CAT16 LTE) downstream, which was introduced in 3GPP Release 12. Today’s implementations have Gigabit LTE paired with LTE Category 13 uplink for uploads up to 150 Mbps. CAT16 LTE is leading to 5G low latency and higher reliability employing 256 quadrature amplitude modulation (QAM), 3×20 megahertz (MHz) carrier aggregation (CA), and 4×4 multiple input/multiple output (MIMO). QAM, CA, and MIMO are combined in various configurations for each LTE Category, resulting in their rated maximum speeds. The actual rated downlink speed achieved through this combination of technologies is not quite 1 Gbps, but close — 979 megabits per second (Mbps).

The telematics units in the car will be the primary data connection to the car, quickly demanding more data as automobile manufacturers try to match smartphone services. Mobile telecommunications carriers and vehicle OEMs will be motivated to monetize telematics data to the car, which will drive increased complexity in telematics systems. The next figure illustrates a telematics cellular front-end module (FEM).

Block Diagram: Telematics Cellular Front-End Module (FEM)

A key advantage of telematics over smartphones is antenna performance. In automobile telematics, the antenna is typically located in the shark fin, outside the car’s metal body. A smartphone located inside a vehicle means the antenna is within the metal body of the car. This degrades antenna performance, unless your dog is using your smartphone, in which case his head is sticking outside the window! Why? Because the vehicle acts like a Faraday cage — a grounded metal screen surrounding a piece of equipment, which excludes electrostatic and electromagnetic influences. To mitigate this Faraday cage effect, vehicle manufacturers are adding all telematics antennas, including cellular, to the shark fin. This allows users to connect their smartphones to the vehicle, thereby eliminating the Faraday cage effect.

Tip: Automakers may be forced to support multiple carriers using Dual subscriber identity module (SIM) dual active (DSDA) technology. You can learn more about DSDA in Chapter 4 of Connected Car For Dummies.

Infotainment: People Interacting with Vehicles

Today’s infotainment systems allow passengers to connect outside the car as well as inside the car. Some infotainment applications include entertainment (including high-definition and satellite radio), navigation, search, and more. Key enabling protocols include Wi‑Fi and Bluetooth (see the following figure).

Automotive Infotainment Connectivity

Wi‑Fi hot spots in the car will be the primary connection that will enable a multi-user interface similar to home Wi‑Fi networks today. Wi‑Fi will deliver 1 Gbps data via the telematics unit in connected cars, to be used by all occupants of the car. The heavy use of Wi‑Fi hot spots and new implementations of V2X will also create new safety challenges in the connected car. For example, V2X and 5 GHz Wi‑Fi will have significant spectrum co-existence challenges that will need to be addressed using innovative filter products.

Filter products reduce out-of-band interferences between radio frequency (RF) bands such as cellular, Wi‑Fi, Bluetooth, and so on. Many of these bands are very close to each other and filtering is required to manage interference between systems. For example, within the 2.4 GHz Wi‑Fi band, there is an increased potential for interference with cellular communications, like band 41 in the 4G LTE band. RF designers use coexistence filters to address the potential for transmitted Wi‑Fi signals to desensitize LTE receiver reception, and for LTE signals to interfere with Wi‑Fi communications. Bulk acoustic wave (BAW) filters are very effective at meeting these requirements.

Tip: To learn more about RF filters, download a free copy of RF Filter Technologies For Dummies and RF Filter Applications For Dummies at www.qorvo.com/design-hub/ebooks/filters-for-dummies.

Filters also aid in providing a safety factor. Proper bandpass filters mitigate interferences between bands such as the cellular LTE band 13 and the public safety band used by the United States public safety services. Without these filters, safety services could be interrupted.

As more vehicle and network services are added, design challenges will follow. The vehicle is becoming crammed with many RF signals, increased data processing, and more functionality. Negotiating the intricate balance between each of these within the vehicle are discussed further in Chapter 4 of Connected Car For Dummies.



Want to learn more about the connected car of the future? Download your free copy of Qorvo’s Connected Car For Dummies e-book.

– Excerpted with permission from John Wiley & Sons, Inc., from Connected Car For Dummies.

QPF4200 Front End Module by Qorvo

Courtesy of Qorvo : QPF4200 Front End Module by Qorvo

The QPF4200 from Qorvo is an integrated front end module (FEM) for Wi-Fi 802.11ax systems. It integrates a 2.4 GHz power amplifier (PA), regulator, SPDT switch, bypassable low noise amplifier (LNA) and DC power detector into a single device. It has a compact form factor and integrated matching minimizes layout area in the application. The performance of the device is focused on optimizing the PA for a 5 V supply voltage that conserves power consumption while maintaining the highest linear output power and leading edge throughput. The receive path matches the optimal technologies to maximize Rx sensitivity through noise figure performance that is consistent over a wider variety of conditions. Integrated die level filtering for 2nd and 3rd harmonics, as well as 5 GHz rejection for DBDC operation, are included.

Product Details

      • Part Number : QPF4200
      • Manufacturer : Qorvo
      • Description : Front End Module for Wi-Fi 802.11ax Systems

General Parameters

      • Type : Transmit / Receive Module
      • Configuration : Power Amplifier, Low Noise Amplifier, Power Detector, Switch
      • Switch Configuration : SPDT
      • Application : WiFi
      • Wireless Standard : 802.11a/n/ac
      • Bands : Single Band
      • Frequency : 2.412 to 2.484 GHz
      • Tx Power : 19 to 22.5 dBm
      • Tx Gain : 31 to 33 dB
      • Voltage : 4.75 to 5.25 V
      • Rx Gain : 15.5 dB
      • Rx Noise Figure : 2.1 dB
      • Package Type : Surface Mount
      • Package : Laminate
      • Dimensions : 3 x 3 mm
      • RoHS : Yes
Qorvo QPF4578

QPF4578 Front End Module by Qorvo

Courtesy of Qorvo : QPF4578 Front End Module by Qorvo

The QPF4578 from Qorvo is a fully integrated Wi-Fi Front-End Module designed for Wi-Fi 802.11a/n/ac/ax systems. The module provides a transmit gain of 31 dB while operating over a supply of 3.3 V. It integrates a 5 GHz power amplifier (PA), single pole two throw switch (SP2T) and bypassable low noise amplifier (LNA) into a single device. There are two options for power detect, a DC power detector which has voltage output and an RF power detector with an RF output from a directional coupler. The QPF4578 integrated die level filtering also includes 2nd and 3rd harmonics and 2.4 GHz rejection for dual-band dual-concurrent operation. It is available in a 5 x 3 mm QFN package and is ideal for wireless routers, IoT, access points and residential gateway applications.

Product Details

    • Part Number : QPF4578
    • Manufacturer : Qorvo
    • Description : 5 GHz Front End Module for Wi-Fi 802.11a/n/ac/ax Systems

General Parameters

    • Type : Transmit / Receive Module
    • Configuration : Switch, Low Noise Amplifier, Power Amplifier
    • Switch Configuration : SPDT
    • Application : WiFi
    • Wireless Standard : 802.11a/n/ac
    • Frequency : 5150 to 5925 MHz
    • Tx Power : 16 to 22 dBm
    • Tx Gain : 29 to 31 dB
    • Tx Current : 270 to 419 mA
    • Voltage : 3 to 3.6 V
    • Rx Gain : 14 to 15 dB
    • Rx Noise Figure : 1.9 to 2.3 dB
    • Rx Current : 18 to 27 mA
    • Package Type : Surface Mount
    • Package : 24 Pin QFN
    • Dimensions : 5 x 3 mm
    • RoHS : Yes
Qorvo-QPA9120

QPA9120 RF Amplifier by Qorvo

Courtesy of everything RF : QPA9120 RF Amplifier by Qorvo

The QPA9120 from Qorvo is a high linearity driver amplifier that operates from 1.8 to 5 GHz. This amplifier delivers 36 dBm of output OIP3 power and 22 dBm of output OP1dB power with 29 dB of gain while consuming less than 100 mA DC current with a single 5V supply. The module is available in a surface mount 3 x 3 mm QFN package and is ideal for 5G massive MIMO, TDD/FDD system, mobile infrastructure and general purpose wireless applications.

Product Details

    • Part Number : QPA9120
    • Manufacturer : Qorvo
    • Description : High Linearity Driver Amplifier from 1.8 to 5 GHz

General Parameters

    • Type : Driver Amplifier
    • Configuration : IC/MMIC/SMT
    • Industry Application : Wireless Infrastructure
    • Frequency : 1.8 to 5 GHz
    • Gain : 29 dB
    • Noise Figure : 1.5 dB
    • P1dB : 22 dBm
    • P1dB : 0.1585 W
    • IP3 : 35 dbm
    • Impedance : 50 Ohms
    • Supply Voltage : 5 V
    • Current Consumption : 96 mA
    • Package Type : Surface Mount
    • Package : 16 Pad QFN
    • Dimensions : 3 x 3 mm
    • Operating Temperature : -40 to 105 Degrees C
    • Storage Temperature : -65 to 150 Degrees C
Qorvo QPF7221

QPF7221 Front End Module by Qorvo

Courtesy of Qorvo QPF7221 Front End Module

The Qorvo QPF7221 is a compact front end module (FEM) for Wi-Fi 802.11b/g/n/ac/ax systems. The FEM integrates a 2 GHz power amplifier (PA), SPDT switch and bypassable low noise amplifier (LNA) and an Rx BAW filter into a single device. It provides state of the art LTE coexistence Rx immunity for maximum range and coverage by integrating high-performance temperature stable BAW filtering on receive chain. The QPF7221 requires a 5V supply without any modifications to the supply lines and performance is a balance of maximizing on highest linear output power and leading-edge throughput. The small form factor and integrated matching minimizes layout area in the application and greatly reduces the number of external components.

Product Details

    • Part Number : QPF7221
    • Manufacturer : Qorvo
    • Description : Compact FEM for Wi-Fi 802.11b/g/n/ac/ax Systems

General Parameters

    • Type : Transmit / Receive Module
    • Configuration : Low Noise Amplifier, Power Amplifier, Switch, Filter
    • Switch Configuration : SPDT
    • Application : WiFi, ISM Band
    • Wireless Standard : 802.11 b/g/n/ac/ax
    • Frequency : 2412 to 2484 MHz
    • Tx Power : 17.5 to 22 dBm
    • Tx Gain : 34 dB
    • Tx Current : 245 to 395 mA
    • Voltage : 3.3 to 2.25 V
    • Rx Gain : 15 dB
    • Rx Noise Figure : 2 dB
Qorvo QPC3025

QPC3025 RF Switch by Qorvo

Courtesy of everything RF : QPC3025 RF Switch

The QPC3025 is a Silicon on Insulator, reflective SPDT switch that operates from 30 to 4200 MHz. It offers low insertion loss in a symmetric topology with excellent linearity. The switch can handle upto 20 W CW and 30 W pulsed power with a 50 Ohm load. The switch is available in a RoHS-compliant, compact 5 x 5 mm surface-mount leadless package and is designed for use in 4G / 5G wireless infrastructure applications and other high performance communications systems.

Product Details

    • Part Number : QPC3025
    • Manufacturer : Qorvo
    • Description : SOI SPDT Reflective Switch from 0.03 to 4.2 GHz

General Parameters

    • Type : Solid State
    • Configuration : SPDT
    • Termination : Reflective
    • Application : 4G, 5G
    • Application Industry : Wireless Infrastructure, Wireless / Communication
    • Frequency : 30 MHz to 4.2 GHz
    • Insertion Loss : 0.35 to 0.41 dB
    • Isolation : 29 to 46 dB
    • Power : 43 dBm(CW), 44.77 dBm(Pulsed)
    • Power : 20 W ( CW), 30 W(Pulsed)
    • Supply Voltage : 2.7 to 5.5 V
    • Control Voltage : 0 to 0.63 (Low), 1.17 to 5.59 (High)
    • Switching Speed : 4.7 to 5.8 us
    • Control : CMOS
    • Impedance : 50 Ohms
    • Package Type : Surface Mount
    • Package : 32 Pin Leadless
    • Dimension : 5 mm x 5 mm
    • Operating Temperature : -40 to 85 Degrees C
    • Storage Temperature : -50 to 150 Degrees C
    • RoHS : Yes
IoT

Qorvo® Introduces IoT SiP to Improve Smart Home Solutions

Courtesy of Qorvo : IoT SiP to Improve Smart Home Solutions

COMMUNICATION CONTROLLER ENHANCED WITH POWER AMPLIFIER DELIVERS BETTER RANGE, LOWER DEVELOPMENT COST AND FASTER TIME TO MARKET

GREENSBORO, NC, – September 14, 2018 – Qorvo® (NASDAQ: QRVO), a leading provider of innovative RF solutions that connect the world, today introduced a new System in Package (SiP) that enables dynamic, simultaneous support for Zigbee® 3.0, Green Power, Thread and Bluetooth Low Energy (BLE). This new SiP integrates Qorvo power amplifier technology providing 20 dBm output, which is especially important for U.S. smart home applications.

The Qorvo QPG6095M is a fully integrated SiP for ultra-low power wireless communications. It is BLE 5.0 and Zigbee 3.0 platform and product certified, and offers Green Power energy efficiency. This SiP also extends range and battery life, and enables robust interference mitigation. The QPG6095M delivers optimized connectivity throughout the home, eliminating the need for complex mesh architectures and unnecessary battery consumption in intermediate devices.

The QPG6095M blends Qorvo’s power amplifier (PA) technology with a multi-standard, multi-protocol chip. Its level of integration and performance benefit product designers by lowering development costs and speeding time to market.

Cees Links, general manager of Qorvo’s Wireless Connectivity business unit, said, “This new SiP is another example of Qorvo’s commitment to combining and leveraging RF technologies to improve the consumer’s connected experience. Developers can now deliver BLE, Zigbee and Thread simultaneously with more range and reliability, and reduce concerns about future compatibility.”

Qorvo’s Wireless Connectivity business is a leading developer of wireless semiconductor system solutions for connected devices and Wi-Fi integrated front-end solutions. Qorvo offers a broad range of advanced RF chips and software for smart home data communications and the IoT.

Information about Qorvo IoT solutions is available at: www.qorvo.com/applications/internet-of-things. Qorvo’s free e-book, Internet of Things for Dummies®, can be accessed here.

To learn more about Qorvo’s Smart Home and IoT solutions visit the Qorvo booth at IBC 2018 (#IBC2018) in Amsterdam (Hall 1, booth A50) on Sept. 14-18.

About Qorvo

Qorvo (NASDAQ:QRVO) makes a better world possible by providing innovative RF solutions at the center of connectivity. We combine product and technology leadership, systems-level expertise and global manufacturing scale to quickly solve our customers’ most complex technical challenges. Qorvo serves diverse high-growth segments of large global markets, including advanced wireless devices, wired and wireless networks and defense radar and communications. We also leverage our unique competitive strengths to advance 5G networks, cloud computing, the Internet of Things, and other emerging applications that expand the global framework interconnecting people, places and things. Visit http://www.qorvo.com to learn how Qorvo connects the world.

Qorvo is a registered trademark of Qorvo, Inc. in the U.S. and in other countries. All other trademarks are the property of their respective owners.

Investor Relations Contact:
Doug DeLieto
VP, Investor Relations
+1-336-678-7088
Media Contact Wireless Connectivity:
Vanessa Gaté
vanessa.gate@qorvo.com
+32-52-454439

This press release includes “forward-looking statements” within the meaning of the safe harbor provisions of the Private Securities Litigation Reform Act of 1995. These forward-looking statements include, but are not limited to, statements about our plans, objectives, representations and contentions and are not historical facts and typically are identified by use of terms such as “may,” “will,” “should,” “could,” “expect,” “plan,” “anticipate,” “believe,” “estimate,” “predict,” “potential,” “continue” and similar words, although some forward-looking statements are expressed differently. You should be aware that the forward-looking statements included herein represent management’s current judgment and expectations, but our actual results, events and performance could differ materially from those expressed or implied by forward-looking statements. We do not intend to update any of these forward-looking statements or publicly announce the results of any revisions to these forward-looking statements, other than as is required under the federal securities laws. Qorvo’s business is subject to numerous risks and uncertainties, including variability in operating results, the inability of certain of our customers or suppliers to access their traditional sources of credit, our industry’s rapidly changing technology, our dependence on a few large customers for a substantial portion of our revenue, our ability to implement innovative technologies, our ability to bring new products to market and achieve design wins, the efficient and successful operation of our wafer fabrication facilities, assembly facilities and test and tape and reel facilities, our ability to adjust production capacity in a timely fashion in response to changes in demand for our products, variability in manufacturing yields, industry overcapacity and current macroeconomic conditions, inaccurate product forecasts and corresponding inventory and manufacturing costs, dependence on third parties and our ability to manage channel partners and customer relationships, our dependence on international sales and operations, our ability to attract and retain skilled personnel and develop leaders, the possibility that future acquisitions may dilute our shareholders’ ownership and cause us to incur debt and assume contingent liabilities, fluctuations in the price of our common stock, additional claims of infringement on our intellectual property portfolio, lawsuits and claims relating to our products, security breaches and other similar disruptions compromising our information and exposing us to liability, the impact of stringent environmental regulations, and the impact of integrating the businesses of RFMD and TriQuint. These and other risks and uncertainties, which are described in more detail in Qorvo’s most recent Annual Report on Form 10-K and in other reports and statements filed with the Securities and Exchange Commission, could cause actual results and developments to be materially different from those expressed or implied by any of these forward-looking statements.

QPB9320 Front End Module by Qorvo

QPB9320 Front End Module by Qorvo

Courtesy of everything RF : QPB9320 Front End Module by Qorvo

The QPB9320 from Qorvo is a front end module developed for TDD macro or picocell base stations that operate from 1.850 to 2.025 GHz. This FEM integrates RF functional blocks such as a pin-diode based high power switch that can handle up to 52 Watts with an LTE signal (8 dB PAR) along with two LNA stages. This Switch/LNA module has a pin diode driver and dc-dc converter circuits integrated into the module and thus requires a single 5 V supply. The control voltage for the switch and gain control mode is with 3.3 V logic.

The QPB9320 is available in a RoHS-compliant, 8 x 8 mm surface-mount leadless package. The switch LNA module is targeted for wireless infrastructure applications configured for TDD-based architectures.

Product Details

    • Part Number : QPB9320
    • Manufacturer : Qorvo
    • Description : High Power Switch LNA Module from 1.850 to 2.025 GHz

General Parameters

    • Type : Transmit / Receive Module
    • Configuration : Low Noise Amplifier, Switch
    • Application : 5G, Cellular
    • Frequency : 1850 to 2025 MHz
    • Tx Power : 21 dBm
    • Voltage : 5 V
    • Rx Gain : 32.5 dB
    • Rx Noise Figure : 1.1 dB
    • Insertion Loss : 0.5 dB
    • Isolation : 54 dB(reverse isolation)
    • Dimensions : 8 x 8 mm
