MFBP-00070CSP3 Band Pass Filter by Marki Microwave
The MFBP-00070CSP3 from Marki Microwave is a Passive MMIC Bandpass Filter with a passband from 17.7 to 25.5 GHz. It has a center frequency of 21.21 GHz with an insertion loss of 1.7 dB and provides a rejection of 30 dBc. This BPF provides a return loss of 20 dB and has a group delay of 304 ps. The filter is designed using GaAs MMIC technology, which enables the production of smaller filter constructions that replace larger form factor constructions. Its tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. This MMIC filter is available in a plastic CSP3 package that measures 3.50 x 3.50 mm.
Product Details
- Part Number: MFBP-00070CSP3
- Manufacturer: Marki Microwave
- Description: Passive GaAs MMIC Bandpass Filter from 17.7 to 25.5 GHz
General Parameters
- Type: MMIC Filter
- Frequency: 17.7 to 25.5 GHz
- Bandwidth: 7800 MHz
- Center Frequency: 21.21 GHz
- Insertion Loss: 1.7 dB
- Return Loss: 20 dB
- Impedance: 50 Ohms
- Package Type: Surface Mount
- Dimension: 3.50 x 3.50 mm
- Operating_Temperature: -55 to 100 Degree C
- Storage_Temperature: -65 to 125 Degree C
- RoHS: Yes
- Note: Group Delay : 304 ps, 1 dBc Passband : 17.67 to 25.46 GHz, 3 dBc Passband : 17.31 to 26.21 GHz
