MFBP-00164GSM1 Band Pass Filter by Marki Microwave

The MFBP-00164GSM1 from Marki Microwave is a Band Pass Filter with Frequency 430 to 990 MHz, Center Frequency 0.65 GHz, Insertion Loss 0.9 dB, Rejection 30 dB, Upper Rejection 30 dB. Tags: Surface Mount. More details for MFBP-00164GSM1 can be seen below.

Product Details

• Part Number: MFBP-00164GSM1
• Manufacturer: Marki Microwave
• Description: Passive Glass Surface Mount Bandpass Filter from 430 to 990 MHz

General Parameters

• Frequency: 430 to 990 MHz
• Center Frequency: 0.65 GHz
• Insertion Loss: 0.9 dB
• Rejection: 30 dB
• Upper Rejection: 30 dB
• Lower Rejection: 30 dB
• Return Loss: 21 dB
• Package Type: Surface Mount
• Dimension: 7.50 x 4.25 mm
• Operating_Temperature: -55 to 100 Degree C
• Storage_Temperature: -65 to 125 Degree C
• RoHS: Yes
• Note: Group Delay : 1600 pS
