ATN03-0040CH Fixed Attenuator by Marki Microwave

The ATN03-0040CH from Marki Microwave is a Fixed Attenuator with Frequency DC to 40 GHz, Attenuation 3.1 dB, Power 2 W, Operating Temperature -55 to 100 Degree C, Storage Temperature -65 to 125 Degree C. Tags: Die. More details for ATN03-0040CH can be seen below.

Product Details

• Part Number: ATN03-0040CH
• Manufacturer: Marki Microwave
• Description: 3.1 dB, Passive GaAs MMIC Fixed Attenuator from DC to 40 GHz

General Parameters

• Frequency: DC to 40 GHz
• Attenuation: 3.1 dB
• Power: 2 W
• VSWR: 1.11:1
• Package Type: Die
• Dimension: 0.60 x 0.75 mm
• Applications: Test Equipment, 5G, Cellular
• Impedance: 50 Ohms
• RoHS: Yes
• Operating Temperature: -55 to 100 Degree C
• Storage Temperature: -65 to 125 Degree C
• Note: Attenuation Flatness : 1.1 dB, Return Loss : 25 dB
