Description
KEY FACTS
-
- High-performance superheterodyne receiver
- Frequencyrange:9 kHz to 4.5/6/9 GHz
- IF and image rejection:>95 dBc(typ.)
- 1 GHz DANL:-168 dBm/Hz(typ.)
- 1 GHz phase noise:<-110 dBc/Hz@10 kHz(typ.)
- 1 GHz phase noise measurement:<-125 dBc/Hz@10 kHz(typ.)
- Analysis bandwidth:50 MHz/100 MHz(opt.50)(typ.)
OPTIONS
- Built-in OCXO reference clock
- Internal high precision GNSS
- 100 MHz analysis bandwidth
| Model | Frequency | Phase Noise 1 GHz, 10 kHz offset |
DANL 1 GHz, Amp On |
Analysis Bandwidth | Sweep Speed RBW = 250 kHz |
|---|---|---|---|---|---|
| NEW SAN-45 | 9 kHz–4.5 GHz | -110 dBc/Hz | -168 dBm/Hz | 50 MHz / 100 MHz (opt.50) | ≥1 THz/s |
| NEW SAN-60 | 9 kHz–6 GHz | -110 dBc/Hz | -168 dBm/Hz | 50 MHz / 100 MHz (opt.50) | ≥1 THz/s |
| NEW SAN-90 | 9 kHz–9 GHz | -110 dBc/Hz | -168 dBm/Hz | 50 MHz / 100 MHz (opt.50) | ≥1 THz/s |
