Description
KEY FACTS
- Frequency range: 9 kHz to 6 GHz
- Standard maximum output level: +7 dBm to +14 dBm
- Extended maximum output level (optional): Up to +25 dBm
- Minimum output level: < -100 dBm
- Phase noise (1 GHz): < -124 dBc/Hz @ 10 kHz offset
- Harmonics (0 dBm output): < -50 dBc (typical)
- Maximum real-time bandwidth: 50 MHz
- Maximum playback output bandwidth: 100 MHz
OPTIONS
- Internal high precision GNSS
- T1 temperature class
- T2 temperature class, only available for core
| Model | Frequency | Phase Noise 1 GHz, 10 kHz offset |
Maximum Output Level | Real-time Bandwidth | Playback Bandwidth |
|---|---|---|---|---|---|
| SGA-60 | 9 kHz-6 GHz | -124 dBc/Hz | 7 dBm-14 dBm | 50 MHz | 100 MHz |
