Description
KEY FACTS
- Frequency range: 9 kHz to 4.5/6/9.5/20/40 GHz
- IF and image rejection: > 95 dBc (typ.)
- 1 GHz DANL: -168 dBm/Hz (typ.)
- 1 GHz phase noise: < -110 dBc/Hz@10 kHz (typ.)
- Analysis Bandwidth: 100 MHz
- 2.5 hours battery time (typ.)
- Channel Power, ACPR, OBM, Phase Noise and More (std.)
OPTIONS
- Built-in OCXO reference clock
- Built-in Tracking Generator.
- Internal high precision GNSS
- 100 MHz analysis bandwidth
| Model | Frequency | Phase Noise 1 GHz, 10 kHz offset |
DANL 1 GHz, Amp On |
Analysis Bandwidth | Weight,Size |
|---|---|---|---|---|---|
| New PXN-45 | 9 kHz-4.5 GHz | -110 dBc/Hz | -168 dBm/Hz | 50 MHz 100 MHz (opt.) |
1.5 kg, 10.1’’ |
| New PXN-60 | 9 kHz-6 GHz | -110 dBc/Hz | -168 dBm/Hz | 50 MHz 100 MHz (opt.) |
1.5 kg, 10.1’’ |
| New PXN-90 | 9 kHz-9 GHz | -110 dBc/Hz | -168 dBm/Hz | 50 MHz 100 MHz (opt.) |
1.5 kg, 10.1’’ |
