MM1-0832LSM RF Mixer by Marki Microwave

MM1-0832LSM RF Mixer by Marki Microwave

The MM1-0832LSM is a double balanced mixer from Marki Microwave with an RF/LO frequency from 8 to 32 GHz and an IF frequency from DC to 12 GHz. This high-frequency X-band GaAs MMIC mixer works well as both an up and down converter. This mixer has a low conversion loss of 8.5 dB and high LO to RF isolation of 36 dB at low LO powers.  The MM1-0832LSM is available in a 3 x 3 mm QFN package and is ideal for 5G, Satcom, Electronic Warfare and Test & measurement applications.

Product Details

    • Part Number : MM1-0832LSM
    • Manufacturer : Marki Microwave
    • Description : GaAs MMIC Double Balanced Mixer from 8 to 32 GHz

General Parameters

    • Type : Double Balanced Mixer
    • Industry Application : Electronic Warfare, 5G, SATCOM, Test & Measurement
    • RF Frequency : 8 to 32 GHz
    • LO Frequency : 8 to 32 GHz
    • IF Frequency : DC to 12 GHz
    • Conversion Loss : 7.5 to 10.5 dB
    • Noise Figure : 11 dB
    • LO Drive – Power : 8 to 15 dBm
    • P1dB : 2 dBm
    • IP3 : 11 dBm
    • LO/RF Isolation : 36 dB
    • LO/IF Isolation : 23 dB
    • Impedance : 50 Ohms
    • Package Type : Surface Mount
    • Operating Temperature : -55 to 100 Degrees C
    • Storage Temperature : -65 to 125 Degrees C
    • RoHS : Yes

Courtesy of Marki Microwave
