The APM-7098CH from Marki Microwave is a RF Amplifier with Frequency 0.1 to 22 GHz, Small Signal Gain 6.5 to 14 dB, Noise Figure 4.6 dB, P1dB 18 dBm, P1dB 63.1 mW. Tags: Chip, Driver Amplifier, Low Noise Amplifier. More details for APM-7098CH can be seen below.

Product Details

  • Part Number: APM-7098CH
  • Manufacturer: Marki Microwave
  • Description: Low Phase Noise Amplifier from 0.1 to 22 GHz

General Parameters

  • Type: Driver Amplifier, Low Noise Amplifier
  • Configuration: Die
  • Standards Supported: 5G
  • Industry Application: Radar, SATCOM, Test & Measurement
  • Frequency: 0.1 to 22 GHz
  • Small Signal Gain: 6.5 to 14 dB
  • Noise Figure: 4.6 dB
  • P1dB: 18 dBm
  • P1dB: 63.1 mW
  • Grade: Space, Military, Commercial
  • IP3: 24 dBm
  • IP3: 251.2 mW
  • Saturated Power: 23 dBm
  • Saturated Power: 199.5 mW
  • Input Power: 16 dBm
  • Input Power: 39.8 mW
  • Impedance: 50 Ohms
  • Reverse Isolation: 38 dB
  • VSWR: 7:1
  • Input Return Loss: 19 dB
  • Output Return Loss: 13 dB
  • Phase Noise: -165 dBc/Hz @ 10 KHz
  • Supply Voltage: 5 to 9 V
  • Current Consumption: 26 to 65 mA
  • Transistor Technology: GaAs HBT
  • Package Type: Chip
  • Operating Temperature: -40 to 85 Degree C
  • Storage Temperature: -65 to 150 Degree C
  • RoHS: Yes
  • Note: Input for Saturated Output (dBm) : 10 dBm
