The MM1-0212S from Marki Microwave is a Double-Balanced GaAs MMIC Mixer with an RF/LO frequency from 2 to 12 GHz and an IF frequency from DC to 3 GHz. It has a conversion loss of less than 11.5 dB and a noise figure of 9 dB. The mixer provides an LO to RF isolation of 47 dB, LO to IF isolation of 49 dB and RF to IF isolation of 39 dB. It is a low frequency, high linearity S band mixer that works well as both an up and down converter to through X band. The mixer is available as both a wire bondable die and a connectorized module.

Product Details

  • Part Number: MM1-0212S
  • Manufacturer: Marki Microwave
  • Description: Double-Balanced Mixer MMIC from 2 to 12 GHz

General Parameters

  • Type: Double Balanced Mixer
  • Industry Application: X Band, S Band
  • Application: Test & Measurement
  • RF Frequency: 2 to 12 GHz
  • LO Frequency: 2 to 12 GHz
  • IF Frequency: DC to 3 GHz
  • Conversion Loss: 8.5 to 14 dB
  • Noise Figure: 9 dB
  • LO Drive – Power: 17 to 23 dBm
  • P1dB: 16 to 18 dBm
  • LO/RF Isolation: 47 dB
  • LO/IF Isolation: 49 dB
  • Impedance: 50 Ohms
  • Package Type: Die, Module with Connectors
  • Connector: SMA, SMA – Female
  • Connector IF: SMA – Female
  • Connector LO: SMA – Female
  • Connector RF: SMA – Female
  • Operating Temperature: -55 to 100 Degree C
  • Storage Temperature: -65 to 125 Degree C
  • Grade: Military, Commercial
  • RoHS: Yes
