MFBP-00160GSM1 Band Pass Filter by Marki Microwave
The MFBP-00160GSM1 from Marki Microwave is a Bandpass Filter (BPF) that has a passband from 2.9 to 4.7 GHz. It provides a 30 dBc rejection both above and below the passband, with an insertion loss of 1.2 dB. This BPF has a passband return loss of 22 dB and a group delay of 591 ps. It is manufactured using advanced glass substrate technology, which enables smaller filter constructions and tighter fabrication, ensuring greater unit-to-unit consistency than legacy filter technologies. This filter is available in an SMT package measuring 7.50 × 4.25 mm.
Product Details
- Part Number: MFBP-00160GSM1
- Manufacturer: Marki Microwave
- Description: Passive Glass SMT Bandpass Filter with Passband from 2.9 to 4.7 GHz
General Parameters
- Frequency: 2.85 to 4.72 GHz
- Bandwidth: 1.87 GHz
- Center Frequency: 3.67 GHz
- Insertion Loss: 1.2 dB
- Rejection: 30 dB
- Upper Rejection: 30 dB
- Lower Rejection: 30 dB
- Return Loss: 22 dB
- Package Type: Surface Mount
- Dimension: 4.25 x 7.5 mm
- RoHS: Yes
- Note: Group Delay : 591 pS
