Addressing Phase Noise Challenges in Radar and Communication Systems: Part 1 Introduction  Phase noise is rapidly becoming the most critical factor addressed in sophisticated radar and communication systems. This is because it is the key parameter defining target acquisition in radars and spectral integrity in communication systems. There are many papers detailing the mathematical derivation...

Custom MMIC CMD162K4 26-34 GHz (K, Ka, Q Band) Low Noise Amplifier The CMD162K4 is a highly efficient GaAs MMIC low noise amplifier housed in a leadless surface mount package. The amplifier is ideally suited for EW and communications systems where small size and low power consumption are needed. The device is optimized for 30...

CMD299 RF Amplifier by Custom MMIC The CMD299 from Custom MMIC is a wideband GaAs MMIC low noise amplifier that operates from 18 to 40 GHz. It provides an output power of up to 7.5 dBm (0.0056 W), a gain of 16 dB, and has a noise figure of maximum 4.6 dB. The amplifier requires...

Introducing New DC to 67 GHz Driver Amplifier with Best-in-class Performance The newly introduced CMD304 is an ultra-wideband GaAs Distributed Driver Amplifier that operates from DC to 67 GHz. This device delivers 9.5 dB of gain with a corresponding noise figure of 3 dB. In addition to providing a very broad frequency range of operation, the CMD304...

The CMD285C3 from Custom MMIC is a RF Variable Attenuator with Frequency DC to 20 GHz, Attenuation Range 35 dB, Power 0.1 W, P1dB 20 dBm, IIP3 30 dBm. Tags: Surface Mount, Voltage Controlled. More details for CMD285C3 can be seen below. Product Details Part Number : CMD285C3 Manufacturer : Custom MMIC Description : 35...

Custom MMIC introduces four new MMIC devices to their growing portfolio of standard products that now numbers over 170. These new products further demonstrate Custom MMIC's commitment to continuous innovation and delivering the highest performing RF and Microwave MMICs in the industry. Part Number Description Package type(s) CMD285C3 DC-20 GHz Variable Voltage Attenuator Ceramic QFN...

The CMD283 is a broadband MMIC low noise amplifier that operates from 2 to 6 GHz (S, C - Band). The device delivers 27 dB of gain with a corresponding noise figure of 0.6 dB at 4 GHz and saturated output power of 18 dBm. It is ideally suited for EW and communications systems where...

New Wideband Medium Power GaAs Amplifier Operating at 20 - 45 GHz We are excited to release CMD293, a wideband medium power GaAs MMIC driver amplifier, ideally suited for military, space and communications systems where small size and high linearity are needed. At 30 GHz the device delivers 20 dB of gain with a corresponding output...

The CMD281C3 is wideband 2-bit digital attenuator that operates from DC to 22 GHz (L, S, C, X, Ku, K Band). Each bit of the attenuator is controlled by a single voltage of either 0 V or -5 V. The attenuator bit values are 2 dB and 4 dB, for a total attenuation of 6…

CMD291 RF Amplifier by Custom MMIC The CMD291 from Custom MMIC is a GaAs MMIC driver amplifier die that operates from 16 to 24 GHz covering the Ku and K Bands. The broadband device is ideally suited for applications requiring a high dynamic range. It delivers a gain of 23 dB with a saturated output power of…
