Qorvo® Adds New GaN Power Amplifiers for Mission-Critical Applications INDUSTRY’S HIGHEST POWER, LINEARITY AND EFFICIENCY MAXIMIZE PERFORMANCE IN KA-BAND AND X-BAND SYSTEMS GREENSBORO, NC – June 3, 2019 – Qorvo® (Nasdaq: QRVO), a leading provider of innovative RF solutions that connect the world, today launched two new gallium nitride (GaN) power amplifier (PA) families for domestic and international...
Read More
The QPA1006D from Qorvo is a wide-band GaN on SiC based power amplifier that operates from 10.7 to 12.7 GHz. It provides an output power of more than 35 watts (46 dBm) and a gain of over 17 dB. The amplifier requires a supply voltage of 20 V. The RF ports of the QPA1006D have...
Read More
Announcing the latest additions to RFMW's portfolio of innovative products from Qorvo, one of our major channel partners. These high-performance solutions simplify RF for designers worldwide and are available for purchase on the RFMW website. High-Power Ku-band Amplifier QPM2239 Features Frequency Range: 13 - 15.5 GHz PSAT (PIN = 25 dBm): 49 dBm PAE (PIN = 25 dBm): > 25...
Read More
The QPB8958 is a GaAs pHEMT/MESFET 75-ohm push-pull RF amplifier IC that provides over 34 dB of flat gain at 1003 MHz. This IC is designed to support DOCSIS 3.1 applications and uses a single 24 V supply. The amplifier provides low noise and low distortion at high efficiency consuming only 5.8 W of input...
Read More
The QPL9098 is an ultra-low noise gain block amplifier that operates from 4 to 6 GHz. At 5.5 GHz, the amplifier provides a gain of 19 dB, OIP3 of 32 dBm and a noise figure of 1.3 dB while drawing 68 mA current from a 4.2 V supply. The LNA integrates a bypass path and...
Read More
The QPF4206B from Qorvo is a 2.4 GHz front end module (FEM) designed for Wi-Fi 802.11ax systems. The FEM consists of a 2 GHz power amplifier (PA), regulator, SPDT switch, and a bypassable low noise amplifier (LNA). The QPF4206B offers 33 dB of Tx gain and 16 dB of Rx gain with LNA noise figure…
Read More
Courtesy of everything RF : QPQ1270 RF Duplexer by Qorvo The QPQ1270 from Qorvo is a RF Duplexer with Frequency 2500-2570 MHz / 2620-2690 MHz, Band 1 2500 to 2570 MHz, Band 2 2620 to 2690 MHz, Power 1 W, Insertion Loss 2.4 dB. Tags: Surface Mount. More details for QPQ1270 can be seen below….
Read More
Courtesy of everything RF : QPF4588 Front End Module by Qorvo The QPF4588 from Qorvo is a front end module for WiFi 6 (802.11ax) access points from 5150 to 5925 MHz. The FEM consists of a 5 GHz power amplifier (PA), regulator, single pole two throw switch (SP2T), bypassable low noise amplifier (LNA), coupler and power…
Read More
Courtesy of Qorvo : QPA2213D RF Amplifier The QPA2213D is a wide band GaN driver amplifier MMIC that operates from 2 to 20 GHz. This amplifier provides over 2 watts of saturated power with a gain of 16 dB and PAE of 23%. It has DC blocking capacitors on both RF ports, which are matched to…
Read More
Courtesy of everything RF : QPQ1907 Band Pass Filter by Qorvo The QPQ1907 from Qorvo is a 2.4 GHz Wi-Fi/BT/LTE Co-Existence BAW Band-Pass Filter. It has extremely steep skirts, simultaneously exhibiting low loss in the Wi-Fi band and high rejection near and in the 2.6 GHz bands. The filter can handle an input power of up…
