0402CT-47NX_RW RF Inductor by Coilcraft The 0402CT-47NX_RW from Coilcraft is a RF Inductor with Inductance 0.047 uH, DC Resistance 900 mOhms, DC Current 180 to 320 mA, Self Resonant Frequency 3.9 GHz, Operating Temperature -40 to 125 Degree C. More details for 0402CT-47NX_RW can be seen below. Product Details Part Number: 0402CT-47NX_RW Manufacturer: Coilcraft Description: 47 nH,...

0201HL-39NXJR RF Inductor by Coilcraft Product Details Part Number: 0201HL-39NXJR Manufacturer: Coilcraft Description: 0.039 uH Ceramic Chip Inductor Optimized for LTE Antenna matching General Parameters Applications: LTE Inductance: 0.039 uH DC Resistance: 1.55 Ohms Bulk Package: Tape and Reel DC Current: 100 mA Dimension: 0.58 x 0.46 x 0.45 mm Self Resonant Frequency: DC to 3.45 GHz...

0908SQ Series RF Inductor by Coilcraft The 0908SQ Series from Coilcraft are Square Air Core Inductors with inductance values from 8.1 to 27.3 nH. They have self-resonant frequencies (SRF) from 2.5 to 5.2 GHz, a DC resistance of less than 10 milli-Ohms, and can handle an RMS current of up to 4.4 A. These inductors have high...

0201CT Series RF Inductor by Coilcraft The 0201CT Series from Coilcraft are Low Profile Wirewound Chip Inductors with inductance values from 0.60 to 22 nH. They have higher Q and lower DCR than similarly sized thin-film types and are optimized for high-frequency impedance matching in applications such as cell phones, wearable devices, Wi-Fi, Bluetooth, GPS, and LTE/5G...

BCR Series RF Inductor by Coilcraft The BCR Series are conical inductors available in nine inductance values ranging from 0.22 to 8.0 uH. They were designed specifically for broadband and high frequency applications across a frequency range of 10 MHz to 40 GHz. The inductors are ideal for use in ultra-wideband bias tees, where the conical inductor...

eBook: The Fundamentals of RF Inductors Explore a variety of technical articles that answer foundational questions about RF inductors and address topics such as solving RF isolation issues with RF inductors, comparing the benefits of wirewound ferrite beads to traditional chip ferrite beads, and designing LC filters with Coilcraft reference designs and software. Download Whitepaper...

Coilcraft New high-current 3x3 mm inductors with very low inductance for fast transient response KTA3030 Series. Ultra-Low Loss Shielded Power Inductor. The KTA3030 Series molded power inductors offer ultra-low inductance values starting from 40 nH, making them ideal for today’s low-voltage, high-current DC-DC converters. Designed for single-phase and multiphase VRMs and PoL regulators, the KTA3030...

0402FL-471XJR_ RF Inductor by Coilcraft The 0402FL-471XJR_ from Coilcraft is a RF Inductor with Inductance 0.47 uH, DC Resistance 0.8 Ohms, DC Current 170 to 330 mA, Self Resonant Frequency 750 MHz, Operating Temperature -40 to 125 Degree C. Tags: Chip Inductor, Wire Wound Inductor. More details for 0402FL-471XJR_ can be seen below. Product Details Part Number:...

0201HL-47NXJR RF Inductor by Coilcraft Product Details Part Number: 0201HL-47NXJR Manufacturer: Coilcraft Description: 0.047 uH Ceramic Chip Inductor Optimized for LTE Antenna matching General Parameters Applications: LTE Inductance: 0.047 uH DC Resistance: 1.7 Ohms Bulk Package: Tape and Reel DC Current: 95 mA Dimension: 0.58 x 0.46 x 0.45 mm Self Resonant Frequency: DC to 3.25 GHz...

WA8514-AE Choke by Coilcraft The WA8514-AE from Coilcraft is an RF Choke with an inductance of 5.6 µH. It is developed for integration into Mini-Circuits’ PHA-202+ monolithic amplifier. This choke has an inductance tolerance of ±20% and a self-resonant frequency of more than 200 MHz. It has a saturation current of 0.73 A and a DC resistance...
