EM Research Legendary Calibration Oscillator

EM Research Legendary Calibration Oscillator

Courtesy of EM Research : Legendary Calibration Oscillator



  • ±0.2 dBm Output Power Variation
  • Output Power to +10 dBm Available
  • Reference from 5 to 100 MHz or Internal
  • Connectorized Package with USB Interface Available
  • Perfect for Testing and Calibration



Meet EM Research’s groundbreaking LCO series: a line of fixed frequency synthesizers with exceptionally low output power variation. These “Legendary Calibration Oscillators” feature an output power variation of ±0.2 dBm over a temperature range of 0ºC to 50ºC, and a variation with power cycle of ±0.1 dBm.

The LCO series excels at meeting these demanding output specifications, making them ideal for use as testing oscillators that require highly stable output power, such as multi-tone intermodulation testing and as calibration sources for receiver chains.



Product Overview:

The LCO series are fixed bandwidth frequency synthesizers that can provide outputs ranging from 1 GHz to 30.5 GHz. LCOs feature extremely low output power variation: ±0.2 dBm over temperature range 0 to 50ºC, and ±0.1 dBm with power cycle. These synthesizers offer output power up to +10 dBm, and can be configured to use either an external reference from 5 to 100 MHz, or an optional internal reference.

LCO synthesizers operate from a +5 V supply and are built in a compact, connectorized package with dimensions 4.5″ x 2.5″ x 0.6″ or smaller. Designed for reliable performance in laboratory and field environments, the LCO series is the perfect fit for a wide range of testing and calibration applications.

Additional customization to your own specifications is available.

GGBSFTP.45.9.A.08 Antenna by Taoglas

GGBSFTP.45.9.A.08 Antenna by Taoglas

Courtesy of everything RF : GGBSFTP.45.9.A.08 Antenna by Taoglas

The GGBSFTP.45.9.A.08 is an embedded stacked passive patch antenna for GPS L1, GPS L2 and GPS L5 bands that supports GLONASS, Galileo and BeiDou. It delivers a gain of up to 2.5 dBi with an efficiency of up to 63%. This right-hand circular polarized antenna measures 45 x 45 x 9 mm and is ideal for Drones, Defense and Automotive applications. The GGBSFTP.45.9.A.08 is mounted via a pin and double sided adhesive. All Terrablast (Taoglas Antenna Series) antennas undergo rigorous temperature, vibration and impact tests and exceed the highest ISO16750 standards.

Product Details

    • Part Number : GGBSFTP.45.9.A.08
    • Manufacturer : Taoglas
    • Description : GPS L1/L2/L5, GLONASS, Galileo and BeiDou Single Feed Patch Antenna

General Parameters

    • Type : Patch
    • Directionality : Omni-Directional
    • Polarization : RHCP
    • Frequency : 1176.45 MHz, 1227.6 MHz, 1575.42 MHz
    • Gain : -4.9 to 2 dB, -0.8 to 2.5 dBi
    • Efficiency : 31 to 65 %
    • Industry : GNSS
    • Mounting : Surface Mount
    • Impedance : 50 Ohms
    • Multi Band : Yes
    • Dimension : 45 x 45 x 9 mm
    • Weight : 41.8 g
    • Operating Temperature : -30 to 85 Degrees C
    • Storage Temperature : -40 to 95 Degrees C
Taoglas Acquires ThinkWireless

Taoglas Acquires ThinkWireless, an Antenna Innovator in the Commercial Vehicle Industry

Courtesy of Taoglas Acquires ThinkWireless, an Antenna Innovator in the Commercial Vehicle Industry

Company’s acquisition will help grow presence in trucking, bus, off-road and motorcycle industry

SAN DIEGO – November 13, 2018 – Taoglas, a leading provider of IoT and automotive antenna and RF solutions, today announced the completion of ThinkWireless, Inc., an antenna provider that specializes in the design, development and production of combination antenna systems for the commercial vehicle market.

The ThinkWireless brand will become ThinkWireless, a Taoglas company. ThinkWireless Founder and Chief Executive Officer Dr. Argy Petros and Director of RF Technology Pierre Wassom will remain.

“Think Wireless has made a name for itself as a designer and developer of high-quality combination antenna systems with deep roots in the commercial trucking industry, where infotainment services, including good quality of service from satellite and AM/FM radio, weather band and GNSS are crucial,” said Ronan Quinlan, Co-CEO, Taoglas. “As we continue to explore potential acquisitions to strengthen the Taoglas brand, we were struck by how similar Think Wireless’ approach to antenna design and manufacturing is to our own commitment to excellence. This is a great acquisition for the Taoglas Group as we look to further expand into new, synergistic markets such as the commercial vehicle industry.”

ThinkWireless, headquartered in Coconut Creek, Florida, specializes in the design, development and production of combination antenna systems that incorporate two or more frequency bands, including those for SiriusXM satellite radio, GPS, AM/FM, weather band, DAB, HDTV, Wi-Fi, Bluetooth, and LTE. The ThinkWireless facilities will become Taoglas’ ninth design and development center globally, and the third in the U.S., alongside centers in San Diego and Minneapolis.

“Taoglas is well-known as a global brand that delivers the highest-quality antennas and RF solutions to the automotive, IoT and other markets,” Petros said. “Taoglas’ global scale and sales channels are unparalleled and will help grow the reach of ThinkWireless’ solutions in the trucking and commercial vehicle industry around the world.”

The ThinkWireless antennas will be available for purchase on the Taoglas website, through key distribution partners and through Taoglas’ Antenna Builder ecommerce marketplace for custom antennas and cable assemblies. For more information on the acquisition and ThinkWireless solutions, visit www.taoglas.com.

Power management solution for Bluetooth Low Energy IoT applications reduces Nordic SoC sleep mode power consumption increasing battery life up to 10x

Courtesy of Nordic Semiconductor : Power management solution for Bluetooth Low Energy IoT applications reduces Nordic SoC sleep mode power consumption increasing battery life up to 10x

Nanopower’s ‘nP-BLE52 module’ can reduce the power consumption of Nordic’s nRF52832 SoC to 10nA in sleep mode and wake up the chip on a predetermined schedule or based on sensor threshold values

Nordic Semiconductor today announces that Skien, Norway-based Internet of Things (IoT) developer, Nanopower, has selected Nordic’s nRF52832 Bluetooth® Low Energy (Bluetooth LE) System-on-Chip (SoC) to provide the wireless connectivity for its ‘nP-BLE52 module’, designed for developers of IoT applications with highly restricted power budgets.

The nP-BLE52 module employs a proprietary power management IC—integrated alongside Nordic’s nRF52832 Wafer-Level Chip Scale Package (WL-CSP) SoC in a System-in-Package (SiP)—which enables it to cut power to the SoC, putting it in sleep mode, before waking it up a pre-set time and in the same state as before it was put to sleep. In doing so the SoC’s power consumption in sleep mode is reduced to 10nA, making it ideal for IoT applications where battery life is critical by potentially increasing cell lifespan 10x.

In active mode, the nRF52832 SoC runs normally. The SoC has been engineered to minimize power consumption with features such as the 2.4GHz radio’s 5.5mA peak RX/TX currents and a fully-automatic power management system. Once the Nordic SoC has completed its tasks, it instructs the nP-BLE52 to put it to sleep and wake it up again at the pre-set time. The nP-BLE52 then stores the Nordics SoC’s state variables and waits until the nRF52832 SoC needs to be powered up again. On wake-up, the device uploads the previous state variables, allowing the Nordic SoC to be restored to the same operational state as before the power was cut. The SoC’s start-up is much more rapid than if it was activated from a non-powered mode.

The nP-BLE52 ‘module’ also features a low power MCU which can be set to handle external sensors and actuators when the Nordic chip is switched off. In this state, the module still monitors sensors and buffer readings and can trigger wake-ups if these readings are above predetermined thresholds, while consuming less less than 1uA. The nP-BLE52 also integrates an embedded inertial measurement unit (IMU).

The module’s power management is controlled through a simple API, whereby the user can predetermine the duration of the Nordic SoC’s sleep mode, set the wake-up time and date parameters, and select pins for other on/off triggers.

While Nanopower sought to dramatically improve power consumption when not transmitting, we selected the nRF52832 because it is the best in class for TX/RX efficiency

Tore Irgens Kuhnle, Nanopower
The module offers IoT developers several advantages, either extending battery life and/or reducing the size of the battery required to power the application thereby reducing the end-product footprint. Longer battery life also reduces or eliminates battery swaps and enables the developer to better adjust for remaining useful battery life as the battery discharges. The module is suitable for any battery-powered device which is not required to be constantly active, for example asset tracking, remote monitoring, beacons, and some smart-home applications.

The nRF52832 WL-CSP SoC measures just 3.0 by 3.2mm while offering all the features of the conventionally-packaged chip. The nRF52832 is a powerful multiprotocol SoC ideally suited for Bluetooth LE and 2.4GHz ultra low-power wireless applications. It combines an 64MHz, 32-bit Arm® Cortex™ M4F processor with a 2.4GHz multiprotocol radio (supporting Bluetooth 5, ANT™, and proprietary 2.4GHz RF software) featuring -96dB RX sensitivity, with 512kB Flash memory and 64kB RAM.

The WL-CSP SoC is supplied with Nordic’s S132 SoftDevice, a Bluetooth 5-certifed RF software protocol stack for building advanced Bluetooth LE applications. The S132 SoftDevice features Central, Peripheral, Broadcaster, and Observer Bluetooth LE roles, supports up to twenty connections, and enables concurrent role operation. Nordic’s unique software architecture provides clear separation between the RF protocol software and the developer’s application code, easing product development.

“While Nanopower sought to dramatically improve power consumption when not transmitting, we selected the nRF52832 because it is the best in class for TX/RX efficiency,” says Tore Irgens Kuhnle, CEO, Nanopower. “The WL-CSP packaging was also important because it allowed us to create a small footprint module.

“We know Nordic very well, and in our experience, support has always been fast and helpful.”

An Introduction to Phase-Locked-Loops and RF Oscillators

Courtesy of Pasternack : An Introduction to Phase-Locked-Loops and RF Oscillators

In most RF systems, the production, transmission, and reception of a radio frequency signal is accomplished by way of a transmitter which amplifies and modulates the signal and a receiver system which feeds the signal into the mixer circuits to enable frequency conversion and demodulation. An oscillator is a circuit that generates a repetitive waveform, often an amplifier, with positive feedback. To control the rate of waveform repetition, frequency selection is accomplished by using capacitors and inductors or resistor and capacitor combinations. Phase-Locked-Loops (PLL) are an important class of oscillator which compares the oscillator output with a reference signal and generates a control voltage based upon the phase difference. The control voltage is then used to “lock” in the phase of the output signal.

Basic PLL Components

In other words, a PLL, is an electronic circuit that locks the phase of the output to the input by way of a negative feedback system that synchronizes the voltage controlled oscillator (VCO) output signal to the phase of a reference input signal. A PLL is made of a variable frequency oscillator which generates a periodic signal and a phase detector which compares the phase of that signal with the phase of the input periodic signal, adjusting the oscillator to keep the phases matched by way of a feedback loop. PLLs can be either analog or digital circuits and have a similar structure made up of four basic elements:

• Phase comparator/detector which is a circuit block component that detects and compares  a phase of two signals and generates a voltage based on the phase difference between the two signals; it generates the phase difference between input signals,

• Loop filter that filters phase comparator output and filters out signals from the voltage controlled oscillator (VCO) line and moderates the stability of the PLL by canceling high frequencies and keeping DC components away from the error signal,

• Voltage controlled oscillator (VCO) is the circuit block that generates the output radio frequency signal and is controlled by the error signal from the phase comparator/detector, and

• Feedback path which may include a frequency divider that directs the operational frequency band for the loop from the output signal to the phase detector.



PLL Applications

PLLs are used in many radio frequency applications and are necessary components in radio frequency equipment including radio receivers, test equipment, demodulators, and frequency synthesizers. Applications include:

• FM demodulation/AM demodulation

• Indirect frequency synthesizers.

• Signal recovery

• Timing distribution

Types of PLLs

• Analog Phase-Locked Loops (PLL/APLL)

First-Order PLL where the loop Filter frequency response is equal to single pole LP filter

Second-Order PLL has greater flexibility and complexity

Used in communication applications

• Digital Phase-Locked Loops (DPLL/ADPLL)

A DPLL has a digital phase detector and an analog VCO and loop filter

An All-Digital PLL (ADPLL) has all digital components

Used in non-communication applications

• Software Phase-Locked Loops (SPLL/ASPLL)

Mostly used for clock/data recovery

High flexibility such that many PLLs can be software implemented

• Neuronal Phase-Locked Loops (NPLL)

Artificial Neural Network (ANN) is a component in the feedback loop

Used for automatic speech recognition and temporal coding in biomedical simulations of the brain

Qorvo® Module Enables Cellular Vehicle-to-Everything Trials by Major Automakers

Qorvo® Module Enables Cellular Vehicle-to-Everything Trials by Major Automakers

Courtesy of Qorvo Module Enables Cellular Vehicle-to-Everything Trials by Major Automakers

INDUSTRY-LEADING FRONT-END MODULE IS AT THE HEART OF QUALCOMM’S C-V2X REFERENCE DESIGN

GREENSBORO, NC – January 2, 2019 – Qorvo® (Nasdaq:QRVO), a leading provider of innovative RF solutions that connect the world, is playing a key role in global field trials of cellular vehicle-to-everything (C-V2X) applications through a powerful front-end module (FEM), a key part of the Qualcomm 9150 chipset reference design. The superior linear output power and thermal management of the Qorvo FEM are essential to supporting the direct, real-time wireless safety communication system between vehicles, bicycles, pedestrians and infrastructure. C-V2X technology is a natural evolution toward the low latency and high bandwidth benefits of 5G for automotive applications.

Qorvo products are designed to solve the toughest automotive RF challenges and support both C-V2X and DSRC protocols. These products will be showcased in Las Vegas during CES (#CES2019), January 8-11, in Qorvo Booth 40943 at the Sands Expo.

Gartner Research estimates there will be 250 million connected vehicles on the roadways by 2020. The Qualcomm 9150 chipset, with the Qorvo QPF1002Q FEM, is currently part of C-V2X trials underway with Audi, PSA, Ford, Nissan and other ecosystem participants spanning projects in Europe, North America, China, Japan, and Korea.

Qorvo’s QPF1002Q is the leading FEM designed specifically to work with the Qualcomm 9150 chipset, providing higher linear output power and improved efficiency for lower temperature operation in automotive applications. This higher power operation results in enhanced range, improved accuracy and higher reliability essential to intelligent, onboard communication systems needed for the connected car and autonomous driving. Qorvo’s FEM includes an HBT PA, PHEMT LNA and PHEMT switch, which combine to enable superior performance over competing technologies.

Gorden Cook, general manager of Qorvo’s Transport business unit, said, “Connected cars of the future will require high levels of precise RF communication with other vehicles, infrastructure and even handsets. The performance, integration, and packaging of our C-V2X module is a key enabler for connected car field trials around the world. Qorvo has teamed with leading automotive OEMs to enable the advanced connectivity that will make connected cars safer, more reliable and more enjoyable.”

C-V2X operates at 5.9 GHz, which presents significant performance challenges to RF front-end components. The QPF1002Q meets the stringent requirements of C-V2X, including 3GPP Release 14 specifications for PC5-based direct communications. Qorvo offers this part with full AEC-Q100 automotive qualification at grade 2 from -40°C to +105°C. Engineering samples of the QPF1002Q are available now.

Qorvo offers a broad portfolio of automotive Wi-Fi, SDARS, GPS and LTE solutions. In addition to meeting ISO/TS 16949 certification, Qorvo performs AEC-Q100 and AEC-Q200 testing to ensure products meet stringent automotive industry requirements. Additional information about Qorvo’s automotive RF solutions, including Qorvo’s Connected Car For Dummies® ebook can be found here.

About Qorvo

Qorvo (Nasdaq:QRVO) makes a better world possible by providing innovative Radio Frequency (RF) solutions at the center of connectivity. We combine product and technology leadership, systems-level expertise and global manufacturing scale to quickly solve our customers’ most complex technical challenges. Qorvo serves diverse high-growth segments of large global markets, including advanced wireless devices, wired and wireless networks and defense radar and communications. We also leverage unique competitive strengths to advance 5G networks, cloud computing, the Internet of Things, and other emerging applications that expand the global framework interconnecting people, places and things. Visit www.qorvo.comto learn how Qorvo connects the world.

Qorvo is a registered trademark of Qorvo, Inc. in the U.S. and in other countries.

Investor Relations Contact:
Doug DeLieto
VP, Investor Relations
+1-336-678-8020
Media Contact:
Katie Caballero
Marketing Communications Manager
Qorvo Infrastructure and Defense Products
+1 972-994-8546
katie.caballero@qorvo.com

This press release includes “forward-looking statements” within the meaning of the safe harbor provisions of the Private Securities Litigation Reform Act of 1995. These forward-looking statements include, but are not limited to, statements about our plans, objectives, representations and contentions and are not historical facts and typically are identified by use of terms such as “may,” “will,” “should,” “could,” “expect,” “plan,” “anticipate,” “believe,” “estimate,” “predict,” “potential,” “continue” and similar words, although some forward-looking statements are expressed differently. You should be aware that the forward-looking statements included herein represent management’s current judgment and expectations, but our actual results, events and performance could differ materially from those expressed or implied by forward-looking statements. We do not intend to update any of these forward-looking statements or publicly announce the results of any revisions to these forward-looking statements, other than as is required under the federal securities laws. Qorvo’s business is subject to numerous risks and uncertainties, including variability in operating results, the inability of certain of our customers or suppliers to access their traditional sources of credit, our industry’s rapidly changing technology, our dependence on a few large customers for a substantial portion of our revenue, a loss of revenue if contracts with the U.S. government or defense and aerospace contractors are canceled or delayed, our ability to implement innovative technologies, our ability to bring new products to market and achieve design wins, the efficient and successful operation of our wafer fabrication facilities, assembly facilities and test and tape and reel facilities, our ability to adjust production capacity in a timely fashion in response to changes in demand for our products, variability in manufacturing yields, industry overcapacity and current macroeconomic conditions, inaccurate product forecasts and corresponding inventory and manufacturing costs, dependence on third parties and our ability to manage platform providers and customer relationships, our dependence on international sales and operations, our ability to attract and retain skilled personnel and develop leaders, the possibility that future acquisitions may dilute our shareholders’ ownership and cause us to incur debt and assume contingent liabilities, fluctuations in the price of our common stock, additional claims of infringement on our intellectual property portfolio, lawsuits and claims relating to our products, security breaches and other similar disruptions compromising our information and exposing us to liability, and the impact of stringent environmental regulations. These and other risks and uncertainties, which are described in more detail in Qorvo’s most recent Annual Report on Form 10-K and in other reports and statements filed with the Securities and Exchange Commission, could cause actual results and developments to be materially different from those expressed or implied by any of these forward-looking statements.

Bluetooth Low Energy-powered hand gesture

Bluetooth Low Energy-powered hand gesture recognition device enables hands-free smartphone operation and audio control whether on the road or in the home

Courtesy of Nordic Semiconductor : Bluetooth Low Energy-powered hand gesture recognition device enables hands-free smartphone operation and audio control

H.P.B HI-TECH CORP’s ‘HPBWAVE1S’ employs Nordic Semiconductor’s nRF51822 SoC to provide low latency wireless connectivity between the device and the user’s smartphone

Nordic Semiconductor today announces that Taiwan-based gesture control solutions developer, H.P.B HI-TECH CORP., has selected Nordic’s nRF51822 Bluetooth® Low Energy (Bluetooth LE) System-on-Chip (SoC) to provide the wireless connectivity for its ‘HPBWAVE1S’, a hand gesture recognition device that enables hands-free audio playback, volume adjustment control, and smartphone operation.

To get started, the device is paired to the user’s Bluetooth 4.0 (and later) Android smartphone running the ‘HPB Wave’ app. Once paired, the user can control certain smartphone functionality via the HPBWAVE1S using a range of hand gesture profiles. For example, in ‘cellphone mode’, waving a hand up in front of the device will answer an incoming call, or waving down will hang up or reject the call. In ‘music mode’, waving up will begin or pause audio playback, while a clockwise or anticlockwise rotation of the finger will either increase or decrease volume. Waving right will skip to the next song, while waving left will play the previous selection.

The Nordic SoC’s powerful Arm CPU was key to our decision to select the nRF51822 SoC, and the feedback during development was both quick and helpful

Holmes Shen, H.P.B HI-TECH CORP

The device integrates an array image sensor and a low power infrared LED to capture the user’s hand gestures, which are in turn relayed to the user’s smartphone using low latency Bluetooth LE wireless connectivity provided by the Nordic SoC, enabling hands-free smartphone operation in the home or while driving.

The HPBWAVE1S is powered by two AAA alkaline batteries, providing between two to three months battery life between replacement under normal operating conditions, thanks in part to the ultra low power characteristics of the nRF51822 SoC which has been engineered to minimize power consumption.

Nordic’s nRF51822 is a powerful and flexible multiprotocol SoC ideally suited for Bluetooth LE and 2.4GHz ultra low-power wireless applications. The nRF51822 is built around a 32-bit Arm® Cortex™ M0 CPU, 2.4GHz multiprotocol radio, and 256kB/128kB Flash and 32kB/16kB RAM. The SoC is supplied with Nordic’s S130 SoftDevice, a Bluetooth 4.2 qualified concurrent multi-link protocol stack solution supporting simultaneous Central/Peripheral/Broadcaster/Observer role connections.

“The Nordic SoC’s powerful Arm CPU was key to our decision to select the nRF51822 SoC, and the feedback during development was both quick and helpful,” says Holmes Shen, Director, H.P.B HI-TECH CORP.

CMD292-Wideband-Distributed-Driver-Amplifier-MMIC

CMD292 RF Amplifier by Custom MMIC

Courtesy of everything RF : CMD292 RF Amplifier by Custom MMIC

The CMD292 from Custom MMIC is a GaAs MMIC distributed driver amplifier die that operates from DC to 30 GHz covering the L, S, C, X, Ku, K, Ka Bands. It delivers a gain of 13 dB with a saturated output power of 28.5 dBm and has a noise figure of 3 dB at 15 GHz. The amplifier requires a supply voltage of 8 to 11 V and consumes up to 250 mA of current. The amplifier is matched to 50 ohms which eliminates the need for external DC blocks and RF port matching. The CMD292 provides full passivation for increased reliability and moisture protection. It can be qualified for space applications if required.

Product Specifications

Product Details

    • Part Number : CMD292
    • Manufacturer : Custom MMIC
    • Description : DC to 30 GHz GaAs MMIC Distributed Driver Amplifier Die

General Parameters

    • Type : Driver Amplifier
    • Configuration : Die
    • Frequency : DC to 30 GHz
    • Gain : 9.5 to 14.5 dB
    • Noise Figure : 3 to 4 dB
    • P1dB : 22 to 27.5 dBm
    • P1dB : 0.15 to 0.56 W
    • IP3 : 30 to 37 dBm
    • Saturated Power : 0.67 W
    • Input Power : 28 dBm
    • Return Loss : 17 to 23 dB
    • Output Return Loss : 15 to 23 dB
    • Supply Voltage : 8 to 11 V
Netatmo Smart Smoke Alarm

Bluetooth Low Energy Netatmo Smart Smoke Alarm offers Apple HomeKit-compatible solution for better home protection

Courtesy of Nordic Semiconductor : Bluetooth Low Energy Netatmo Smart Smoke Alarm offers Apple HomeKit-compatible solution for better home protection

The Netatmo Smart Smoke Alarm employs Nordic Semiconductor nRF52832 SoC wireless connectivity to send real time alerts to the user’s smartphone or tablet

Nordic Semiconductor today announces that the leading French smart home company, Netatmo, has selected Nordic’s nRF52832 System-on-Chip (SoC) to provide the Bluetooth® Low Energy (Bluetooth LE) wireless connectivity for its Smart Smoke Alarm. The Netatmo Smart Smoke Alarm triggers an alarm of 85dB and sends a real-time alert to a user’s smartphone. It also indicates in which room the smoke is detected.

Once installed, the Smart Smoke Alarm can be paired to the user’s Bluetooth 4.0 (and later) smartphone or tablet using Bluetooth LE wireless connectivity provided by the Nordic SoC. From the Netatmo Security app the user can review the status of one or more Smart Smoke Alarms, set up sound test reminders, as well as check when the unit last self-checked its battery, smoke sensor, and Wi-Fi connection. The user can also use the Smart Smoke Alarm ‘Hush’ feature to silence the alarm directly from their smartphone. Compatible with Apple HomeKit, the device can be also be voice controlled via Apple’s Siri. Users can ask the voice assistant if there is smoke in the home or if the device’s batteries are working properly.

Battery life is enhanced by the nRF52832 SoC’s design which minimizes power consumption

The Smart Smoke Alarm is powered by two non-replaceable lithium batteries with a 10-year lifespan, which covers the entire service life of the device. Battery life is enhanced by the nRF52832 SoC’s design which minimizes power consumption with features such as the 2.4GHz radio’s 5.5mA peak RX/TX currents and a fully-automatic power management system that reduces power consumption by up to 80 percent compared with Nordic’s nRF51 Series SoCs.

Nordic’s nRF52832 SoC is a powerful multiprotocol SoC ideally suited for Bluetooth LE and 2.4GHz ultra low-power wireless applications. The nRF52832 combines an 64MHz, 32-bit Arm® Cortex™ M4F processor with a 2.4GHz multiprotocol radio (supporting Bluetooth 5, ANT™, and proprietary 2.4GHz RF software) featuring -96dB RX sensitivity, with 512kB Flash memory and 64kB RAM.

The SoC is supplied with Nordic’s S132 SoftDevice, a Bluetooth 5-certifed RF software protocol stack for building advanced Bluetooth LE applications. The S132 SoftDevice features Central, Peripheral, Broadcaster, and Observer Bluetooth LE roles, supports up to twenty connections, and enables concurrent role operation. Nordic’s unique software architecture provides clear separation between the RF protocol software and the developer’s application code, easing product development.

The benefits of concurrent dual-channel V2X

The benefits of concurrent dual-channel V2X

Courtesy of u-blox : The benefits of concurrent dual-channel V2X

Two eyes see more than one. The same is true for V2X receivers.

Vehicle‑to‑everything, or V2X, is a groundbreaking technology with the potential to dramatically improve road safety, saving thousands of lives each year. Developed and tested over decades, it uses wireless communication to offer vehicles 360 degree awareness of what’s going on around them, beyond line of sight, and with up to one kilometer range.

The only mature and ready‑to‑deploy V2X solution uses the DSRC[1]/IEEE 802.11p wireless standard to let vehicles communicate directly with each other, with road‑side infrastructure, with pedestrians, as well as everything else. Initial benefits include early warnings of traffic incidents for increased safety and smart traffic management for smoother traffic flow. Looking further down the road, V2X will play a key role in enabling autonomous driving.

The UBX‑P3: 100% u‑blox

After two successful generations of u‑blox V2X modules based on third‑party V2X chips, we announced the UBX‑P3 chip, our V2X solution built entirely in‑house, earlier this year. Not only does the UBX‑P3 strengthen the overall DSRC/IEEE 801.22p market offering, the decision to build it from the bottom up gave us freedom to design the chip to meet needs that we observed in the market. One of them is concurrent dual‑channel communication.

If you know anything about the automotive industry, you know that it is heavily regulated to ensure that high quality standards are met. This is as true for V2X as it is for a car’s airbags, its brakes, and its windshield wipers. Ensuring the reception of all safety messages, whether from other vehicles or from nearby infrastructure, is a must for your safety.

The IEEE 1609.4 standard on multi‑channel operation enables such operation with channel switching using a single radio. So why did we implement concurrent dual‑channel communication on our V2X chip?

It’s simple. Two eyes see more than one. The same is true for V2X receivers. On the road, this translates to increased reliability, robustness, and, ultimately, safety.

Understanding DSRC/IEEE 802.11p channels

But before we get into exactly how concurrent dual‑channel V2X communication can be exploited, let’s take a look at some basics of DSRC/IEEE 802.11p V2X communications.

In Europe and the US, the DSRC/IEEE 802.11p spectrum spans 75 MHz in the 5.9 GHz band, and is divided into 7 channels. In both regions, one channel acts as a control channel. Two (Europe), respectively six (US), of the remaining channels are service channels, which may be dedicated to specific communications. South Korea has adopted a similar set up as Europe and the US, while Japan has reserved a single 10 MHz channel centered at 760 MHz for the technology.

Because of their simpler design, single channel V2X solutions are more cost effective than dual‑channel ones. But because they only have a single receiver channel to monitor multiple communication channels, their available bandwidth to monitor safety messages is cut by at least 50%, reducing the safety benefits and the applications that can be deployed. Dual‑channel operation allows to maximizing the V2X safety benefits by tuning one channel to receive safety messages, while the other can be used for other applications.

Key use cases of concurrent dual‑channel communication

Depending on the context, dual‑channel V2X can be configured to continuously follow two communication channels to ensure that no safety messages are lost. Alternatively, one receiver can be set up to constantly stay on the pulse of incoming safety messages, while the second receiver alternates between the control and service channels.

Another interesting use case is truck platooning, in which trucks travel in compact formations to reduce the air drag acting on trailing vehicles, which cut their fuel needs upwards of 13%. V2X is the technology of choice to ensure safety of truck platoons, even at high velocities. Using concurrent dual‑channel communication, one of the available channels can be dedicated to communication between two trucks, while the other channel handles communication with surrounding vehicles.

The UBX‑P3 is the smallest, most power‑efficient V2X chip on the market. Designed to meet the most stringent automotive applications, it is secure and fully compatible with the main global standards, and features an integrated power management unit. There is much more to the UBX‑P3 than concurrent dual‑channel communication. Our on demand V2X webinar looks at other notable highlights, such as single channel diversity, and offers an introduction into V2X, the similarities and differences between DSRC and C‑V2X, and key applications and verticals that the technology will benefit.


[1] DSRC stands for Dedicated Short Range Communication.
