Marki Microwave introduces their first 50 GHz surface mount products, the MM1-1850HSM and MM1-1850SSM double-balanced mixers. These GaAs MMIC mixers offer wide bandwidths and high linearity in a proprietary surface mount package. With an RF bandwidth of 18 to 50 GHz and IF of DC to 21 GHz these are ideally suited for electronic warfare, radar,...

High Linearity Triple-Balanced MMIC Mixer for S, C, X-Band The MT3L-0113HSM is a lower IF variant of our popular MT3H-0113HSM triple-balanced MMIC mixer. It offers similar linearity performance to our T3-07, T3-12, and MT3-0113CQG mixers with smaller size, better availability, and a lower price. Greater than +30dBm IIP3 can be achieved when paired with our ADM...

The MFB-1100 from Marki Microwave is a Band Pass Filter with Frequency 9 to 13 GHz, Bandwidth 3 GHz, Center Frequency 11 GHz, Insertion Loss 2 to 3 dB, Rejection 20 to 50 dB. Tags: Die. More details for MFB-1100 can be seen below Product Details Part Number : MFB-1100 Manufacturer : Marki Microwave Description…

The MMIQ-1865H from Marki Microwave is a passive GaAs MMIC IQ mixer with a RF/LO frequency range from 18 to 65 GHz and IF range from DC to 23 GHz. It provides up to 35 dB of image rejection due to the excellent phase and amplitude balance of its on-chip LO quadrature hybrid. The mixer…

K/Ka/V-Band IQ Mixer Features Massive 23 GHz IF Bandwidth This is our best mmwave IQ mixer yet! The MMIQ-1865L/H features an astounding 50dB of L-to-R isolation across a wide 18 to 65 GHz frequency range. Combined with 23 GHz of IF bandwidth, this MMIC mixer is the ideal solution for wideband IQ and vector modulation,...

Courtesy of everything RF : MT3L-0113H RF Mixer by Marki Microwave The MT3L-0113H from Marki Microwave is a GaAs triple balanced MMIC mixer with an RF/LO frequency from 1.5 to 13 GHz and IF frequency from 0.25 to 5 GHz. The mixer has a conversion loss of 8.5 dB, isolation of 43 dB and a high…

Courtesy of Marki Microwave : New High Linearity, High Isolation Mixers in Bare Die, SMT, and Module High Linearity Triple-Balanced MMIC Mixer for S, C, X-Band The MT3L-0113H is a lower IF variant of our popular  MT3H-0113H triple-balanced MMIC mixer. Greater than +30dBm IIP3 can be achieved when paired with our ADM series of square-wave generating LO driver…

Courtesy of everything RF : MM1-1850S RF Mixer by Marki Microwave The MM1-1850S from Marki Microwave is a RF Mixer with RF Frequency 18 to 50 GHz, LO Frequency 18 to 50 GHz, IF Frequency DC to 20 GHz, Conversion Loss 8.5 dB, P1dB 14 dBm. Tags: Die, Module with Connectors, Double Balanced Mixer. More details…

Courtesy of Marki Microwave : New active Doubler Modules Produce High Power from 4 to 30 GHz Marki Microwave’s two new unique frequency doublers provide wide output bandwidths, high output power and high harmonic suppressions. The ADA-0416 output spans 4 to 16 GHz and the ADA-1030 covers 10 to 30 GHz. Both are active devices accepting…

Courtesy of Marki Microwave : QH-0R518 3 dB Quadrature (90 degree) Hybrid Coupler Quad Hybrid Features Industry-Best 36:1 BW Ratio The new QH-0R518 quadrature hybrid coupler achieves an astounding 36:1 bandwidth ratio, from 0.5 GHz to 18 GHz. Featuring excellent amplitude and phase balance, high 20dB isolation, and 20W power handling this 90 degree quad coupler enables…
